Swamp Type Tracked Pipelayer (DGY90)
Wuhan Kudat Industry & Trade Co., Ltd.- Max. Lifting Capacity：90, 000 Kg
- Boom Length：8.6 M
- Max. Lifting Height of Boom：7.1 M
- Engine：Cummins Nta855-C360
- Chassis Model：Dgy90
- Engine Powe：257,2000kw,Rpm
Base Info
- Model NO.：DGY90
- Track Length on Ground：3620 Mm
- Hydraulic Pump Model：Cby4125,4100,K1008
- Wire Rope Diameter：22 Mm
- Max. Grade Ability：22%
- Transport Package：in Nude Package
- Specification：CE
- Trademark：Kudat
- Origin：CHINA
- HS Code：87169000
- Production Capacity：500units,Month
Description
Max. lifting capacity of boomTon 90 Max. lifting moment at min. range of the boom (882kN * 1.22M) kN.m 1076 Max. lifting moment at max. range of the boom (127.4kN * 7.0M) kN.m 891.8 Boom length m 8.6 Max. lifting height of the boom m 7.1 Hoisting speed (6times) m/min 6 Time of change range s 60 Chassis model DGY90 Engine model CUMMINS NTA855-C360 Engine power kW/rpm 257/2000 Track gauge mm 2480 Track length on ground mm 3620 Track shoe width mm 860 Hydraulic pump model CBY4125/4100/K1008 Hydraulic pump pressure Mpa 20 Lifting winch Hydraulic driven, planetary transmission, free-fall function Rated pulling force of single rope (3rd layer) N 120,000 Wire rope diameter mm 22 Ranging winch Hydraulic driven, planetary transmission Rated pulling force of single rope (2nd layer) N 100,000 Max. grade ability o 22 Operation temperature (std.) o C -20 ~ +40 Overall dimension (LxWxH) with boom mm 5700*4950*9210 without boom mm 5700*3470*3300 Ground pressure without load Mpa 0.105 Operation weight kg 58,000
