• Model NO.：XGC200
• Boom Length：19~82 M
• Fixed Jib Length：13~31 M
• Max. Mass of Single Unit in Transport St：30 T
• Warranty：1 Year
• Transport Package：Nude Package
• Specification：ISO, CE, GOST
• Trademark：ORIEMAC
• Origin：Jiangsu, China(Mainland)
• HS Code：84295212
• Production Capacity：800PCS,Month

Basic Info.

Model NO. XGC200 Boom Length 19~82 M Fixed Jib Length 13~31 M Max. Mass of Single Unit in Transport St 30 T Warranty 1 Year Transport Package Nude Package Specification ISO, CE, GOST Trademark ORIEMAC Origin Jiangsu, China(Mainland) HS Code 84295212 Production Capacity 800PCS/Month

Product Description

ORIEMAC 200 Ton XGC200 Lifting Construction Equipment Hydraulic Crawler Crane

Overview

XGC2000 crawler crane

XGC200 is a new generation crawler crane which is independently developed by ORIEMAC. It adheres to ORIEMAC design concept of "safety, reliability, environment protection, advance, emphasize detailed structure and represent humanistic thought.

Three working conditions are equipped for this crane model, including boom working condition, fixed jib working condition and luffing jib working condition, with strong lifting capacity.

The max rated lifting capacity/radius in boom working condition reaches 200t/5m, while the max lifting capacity for luffing jib and fixed jib are 50t and 33.5t respectively, the max load moment is 1043.8tm.

For this crane, the max weight of single unit in transport state is 30t, transport width is only 3m.


Parameter Item	Unit	Parameter value
Operation performance parameter		*
Max. rated lifting capacity for boom	(t)	200
Max. rated lifting capacity for fixed jib	(t)	33.5
Max. rated lifting capacity for luffing jib	(t)	50
Max. load moment	(t.m)	1043.8
Max. rated lifting capacity for tower jib	(t)	50
Max. rated lifting capacity for boom single top	(t)	-
Max. rated lifting capacity for special jib	(t)	-
Dimension parameter		*
Boom length	(m)	19~82
Boom luffing angle	(°)	30~83
Fixed jib length	(m)	13~31
Tower jib length	(m)	20~59
Max. dimension of single unit in transport state (L×W×H)	(m)	9.58×3.0×3.3
Fixed jib offset angle	(°)	15,30
Special jib length	(m)	-
Speed parameter	(m/min)	*
Max. single line speed for hoist mechanism	(m/min)	120
Max. single line speed for boom luffing mechanism	(m/min)	2×34
Max. single line speed for jib luffing mechanism	(m/min)	41.6
Max. slewing speed	(m/min)	1.5
Max. travel speed	(m/min)	1.3
Grade ability	(%)	30
Mean ground pressure	(MPa)	0.112
Max. single line speed for tower jib luffing mechanism	(m/min)	41.6
Max. single line speed for superlift luffing	(m/min)	-
Engine		*
Model		SC9D
Engine power	(kW)	243
Emission		National III
Mass parameter		*
Overall crane mass	(t)	176(main hook, all counterweights, 19m boom)
Max. mass of the single unit in transport state	(t)	30
