• Model NO.：deyuan
• Running Mode：Stationary
• Certification：CE, ISO 9001
• Standard：National Standards
• Driven Mode：Electric Operated
• Chain Size：12.5mm to 120mm
• Transport Package：1sets Per Wooden Case
• Specification：CCS, BV, GL.
• Trademark：Deyuan
• Origin：China
• Production Capacity：60sets Per Month

Basic Info.

Model NO. deyuan Running Mode Stationary Certification CE, ISO 9001 Standard National Standards Driven Mode Electric Operated Chain Size 12.5mm to 120mm Transport Package 1sets Per Wooden Case Specification CCS, BV, GL. Trademark Deyuan Origin China Production Capacity 60sets Per Month

Product Description

Boat Diesel Engine Double Power Driven Marine Winch


 Boat Diesel Engine Double Power Driven Marine Winch

A marine winch is one of the marine equipment used during mooring operations to hold a boat in place at a pier or similar fixture.

The marine winch can be driven by electric and hydraulic and diesel engine . As you can see our below Electric And Diesel Engine Double Power Driven Marine Winch .It can be driven by electric or diesel engine. That means it is the double power driven winch. Deyuan marine can design the ship marine winch according to your specific requirement.

All our boat marine winches are approved by CCS,ABS,DNV,BV,NK,RINA,BKI. Deyuan marine can offer you the marine winch with hight quality and best price. Pls feel free to contact deyuan marine sales team for more details.

Electric And Diesel Engine Double Power Driven Marine Winch Technical parameter:

Drum 1

Working load: 28.7KN

Holding load: 175KN

Rated speed: 9m/min

Cable dia Φ19mm

Rope capacity: 500m

Drum 2

Working load: 80KN

Holding load: 240KN

Rated speed: 9m/min

Cable dia: Φ28mm

Rope capacity: 100m
