40ton Slipway Winch for Pulling 2000t Ship on Rail Cradle up From Sea
Pingyang Construction Hoisting Machinery Co.- Type：Electric Winch
- Driven Type：AC
- Speed：Slow
- Carrying Capacity：Special Weight Level
- Tonnage：40ton
- Reel Number：1
Base Info
- Model NO.：JM40ton
- Running Mode：Stationary
- Feature：Drum Can Free
- Certification：ISO 9001
- Standard：Nonstandard
- Motor：ABB or Normal Brand
- Line Pull Capacity：40ton
- Rope Capacity：800m
- Brake：Double Brake
- Transport Package：Naked
- Trademark：CH
- Origin：Wenzhou, China
- HS Code：8425319000
- Production Capacity：1 Set Per Month
Description
Model
JM20
JM30
JM40
Rated load (kg)
20000
30000
40000
Wire rope average speed (m/min)
10
10
10
Wire rope( mm):
39
42
48
Reduction box
Type
JZQ750
JZQ850
JZQ850
Transmission ratio
31.5
40.17
23.34
Drum (mm)
Diameter(mm)
750
960
1100
Length
1830
1960
1460
Capacity(m)
600
650
800
Motor
voltage
380V/50H
380V/50H
380V/50H
Power(kW)
45
75
90
Rotate speed(r/min)
965
969
720
Electric-hydraulic Brake Type
YWZ-400
YWZ-400
YWZ-500
Dimension (mm)
4000x3000x1700
4500 x2300 x220 0
5500 x2800 x2200
Weight(kg)
8500
11000
19000
