Electric Windlass for Pulling Boat up and Down Sea Water

Pingyang Construction Hoisting Machinery Co.
  • Type：Construction Winch
  • Driven Type：AC
  • Speed：Slow
  • Carrying Capacity：Special Weight Level
  • Tonnage：30T
  • Reel Number：1

Base Info

  • Model NO.：JM
  • Running Mode：Stationary
  • Certification：ISO 9001
  • Standard：National Standards
  • Transport Package：Wooden Case
  • Specification：JK5
  • Trademark：CH
  • Origin：China
  • HS Code：8425319000
  • Production Capacity：10000 Units,Year

Description

ModelJM2JM3JM5JM8JM10Line pull capacity (kg)200030005000800010000average speed (m/min)1210101010Wire rope(mm):12.515.521.52630Reduction boxTypeJZQ350JZQ350JZQ400JZQ500JZQ650Transmission ratio23.3431.523.3431.540.17Drum (mm)Diameter/mm273325406500530Length4805206459001000Capacity(m)150180250300350motorTypeYZ160M2-6YZ160M2-6YZ160L-6YZR225M-6YZR225M-6Power(kW)7.57.5112230Rotate speed(r/min)948948953720962Hydraulic BrakeYWZ-200/25YWZ-200/25YWZ-300/45YWZ-300/45YWZ-300Packing Dimension (mm)1060x1500x7501600x1100x8201400x1910x9502050x1640x10002470x2280x1180G. Weight(kg)630680140030004000 Electric Windlass for Pulling Boat up and Down Sea WaterElectric Windlass for Pulling Boat up and Down Sea WaterElectric Windlass for Pulling Boat up and Down Sea WaterElectric Windlass for Pulling Boat up and Down Sea WaterElectric Windlass for Pulling Boat up and Down Sea Water
