• Model NO.：ZS1212HD
• Certification：GS, CE, RoHS, ISO 9001
• Transport Package：in Nude
• Specification：2.49*1.15m*2.05m
• Trademark：Zoomlion
• Origin：China
• Production Capacity：5000PCS,Year

ModelZS1212HDSizeWork Height13.80mA - Platform   Height-Elevated11.80mB - Platform   Height-Stowed1.46mC - Platform   Length2.30mD - Platform Width1.12mPlatform Extension0.91mE - Overall Height (Rails Up)2.59mOverall Height (Rails Down)2.05mF - Overall Length2.49mG - Overall Width1.15mH - Wheelbase1.85mI - Ground Clearance (Stowed)0.11mJ - Ground   Clearance (Raised)0.02mPerformancePlatform Capacity350kgCapacity on Deck Extension113kgMax. Number of Workers3Drive Speed (Stowed)3.5km/hDrive Speed (Raised)0.8km/hTurning Radius (Inside)0.1mTurning Radius (Outside)2.2mUp/Down Drive Motor24V/4.5KWUp/Down Time62s/42sGradeability25%(14°)Max. Working Slope (Lateral/Vertical)1.5°/3°ControlProportional   ControlDriveFront WheelsBrakeRear WheelsTire381mm×127mmPowerBattery4×12V/300AhCharger24V/30AWeightGross3180kg
