• Model NO.：GTBZ20SU
• Feature：Explosion-Proof, Insulating
• Certification：GS, CE, RoHS, ISO 9001
• Max. Working Height：20.30m
• Max. Allowable Cargo：900kg
• Max. Horizontal Reach：12.10m
• Transport Package：Nude
• Specification：20m
• Trademark：DINGLI
• Origin：China
• HS Code：8705905900
• Production Capacity：100units Per Month

ModelGTBZ20SUMax. Working Height20.30mMax. Platform Height18.30mMax. Horizontal Reach12.10mMaximum Rearward4.09mPlatform Slider Boom2.19mOverall Length7.68mOverall Width2.46m/2.30mOverall Height(Rails Up / Rails Down/transport)2.89m/3.80m/2.59mPlatform Size(Lengt / Wide6.70×2.24mGround Clearance0.37mWheel Base4.00m
PerformanceModelGTBZ20SUS.W.L1350kgGoods900kgMax. occupants4Turning Radius(Inside/Outside)3.24m/4.97mTurret Rotation±90°Travel Speed(Stowed)6.00km/hTravel Speed(Working)0.90km/hGradeability40%Maximum Slope3°/5°Chassis Leveing10°Tyre385-65
PowerModelGTBZ20SUEngine  Deutz TD2.9- L436kw/2600rpmFuelDieselHudraulic Tank216LFuel Tank160L
