• Model NO.：CD
• Certification：CE, GOST
• Condition：New
• Color：Green
• Working Class：M3
• Electric System：Siemens
• ISO 9001: 2008：Passed
• ISO 14001: 2004：Passed
• Ohsas 18001: 1999：Passed
• Weight Overload Protective Device：Included
• Current Overload Protectiion Function：Included
• Voltage Lower Protection Function：Included
• Transport Package：Polywood Case
• Specification：GB12476.1-2000
• Trademark：Kuangyuan
• Origin：Henan, China
• HS Code：84251100
• Production Capacity：18000sets Per Year

Capacity (ton)
0.5
1
2
3
5
10
16
20
Lifting height (m)
6, 9, 12, 18, 24, 30
Working duty
M3
M6
Control way
Pendant control, or Remote control
Power source
380V 50HZ 3phase (Could supply it as yours)
I-beam type
16-28b
20a -32c
25a -63c
45a-63c
Lifting mechanism
Electric hoist model
CD1 single speed, MD1 double speed
Wire rope
Diameter
4.8
7.4
11
13
15
15
17.5
20
Structure form
D-6 × 37+1
Lifting speed (m/min)
Single
8
7
3.5
Double
0.8 / 8
0.7 / 7
0.35/3.5
Motor power (KW)
Single speed
0.8
1.5
3
4.5
7.5
13
13
18.5
Double speed
0.2/0.8
0.2/1.5
0.4/3
0.4/4.5
0.8/7.5
1.5/13
1.5/13
3.0/18.5
Rotation speed (n/min)
1380
1400
Traveling mechanism
Traveling speed (m/min)
20 or 30
Motor power (KW)
0.2
0.2
0.4
0.4
0.8
2 × 0.8
2 × 0.8
4 × 0.8
Rotation speed (n/min)
1380
