200 Ton High Tonnage Hydraulic Jack
SOV Hydraulic Technology (Shanghai) Co., Ltd.- Type：Hydraulic Jack
- Structure：Hydraulic Jack
- Capacity (Load)：50-1000t
- Power Source：Hydraulic
- Max Height：-
- Certification：CE, ISO 9001:2008
Base Info
- Model NO.：SOV-CLRG series
- Condition：New
- Products Name：200 Ton High Tonnage Hydraulic Jack
- Cylinder Capacity(T)：50-1000 Ton
- Stroke(mm)：50-300 mm
- Collapsed Height：166-815mm
- Weight(Kg)：17-1439
- Working Pressure(MPa)：700
- Warrenty：1 Year
- OEM：Yes
- Outside Diameter：130-560mm
- Color：Black or Yellow
- Transport Package：Standard Export Wooden Box
- Specification：CE, ISO
- Trademark：SOV
- Origin：China
- HS Code：8412210000
- Production Capacity：500 PCS,Month
Description
Maximum
Cylinder Capacity
(kN)Cylinder
Effective Area
(cm2) Oil
Capacity
(cm3) Coll. Height
(A) Ext.
Height
(B) Outside
Dia.
(D) Weight ton mm Push Pull Push mm Push Pull mm mm mm kg SOV-CLRG-502 50 50 539 269 77,0 38,5 385 192 162 212 130 17 SOV-CLRG-504 100 539 269 77,0 38,5 770 385 212 312 130 20 SOV-CLRG-506 150 539 269 77,0 38,5 1155 577 262 412 130 23 SOV-CLRG-508 200 539 269 77,0 38,5 1540 770 312 512 130 27 SOV-CLRG-5010 250 539 269 77,0 38,5 1924 962 362 612 130 31 SOV-CLRG-5012 300 539 269 77,0 38,5 2309 1155 412 712 130 34 SOV-CLRG-1002 100 50 929 433 132,7 61,9 664 309 179 229 165 29 SOV-CLRG-1004 100 929 433 132,7 61,9 1327 619 229 329 165 34 SOV-CLRG-1006 150 929 433 132,7 61,9 1991 928 279 429 165 40 SOV-CLRG-1008 200 929 433 132,7 61,9 2655 1237 329 529 165 46 SOV-CLRG-10010 250 929 433 132,7 61,9 3318 1546 379 629 165 52 SOV-CLRG-10012 300 929 433 132.7 61,9 3982 1856 429 729 165 58 SOV-CLRG-1502 150 50 1390 675 198,6 96,5 993 482 196 246 205 39 SOV-CLRG-1504 100 1390 675 198,6 96,5 1986 965 246 346 205 52 SOV-CLRG-1506 150 1390 675 198,6 96,5 2978 1447 296 446 205 65 SOV-CLRG-1508 200 1390 675 198,6 96,5 3971 1930 346 546 205 78 SOV-CLRG-15010 250 1390 675 198,6 96,5 4964 2412 396 646 205 92 SOV-CLRG-15012 300 1390 675 198,6 96,5 5957 2895 446 746 205 105 SOV-CLRG-2002 200 50 1861 889 265,9 127,0 1330 635 212 262 235 55 SOV-CLRG-2006 150 1861 889 265,9 127,0 3989 1905 312 462 235 91 SOV-CLRG-20012 300 1861 889 265,9 127,0 7977 3809 462 762 235 146 SOV-CLRG-2502 250 50 2565 1068 366,4 152,6 1832 763 235 285 275 89 SOV-CLRG-2506 150 2565 1068 366,4 152,6 5497 2289 335 485 275 136 SOV-CLRG-25012 300 2565 1068 366,4 152,6 10993 4578 485 785 275 207 SOV-CLRG-3002 300 50 3193 1060 456,2 151,4 2281 757 322 372 310 184 SOV-CLRG-3006 150 3193 1060 456,2 151,4 6843 2270 422 572 310 232 SOV-CLRG-30012 300 3193 1060 456,2 151,4 13685 4541 572 872 310 303 SOV-CLRG-4002 400 50 3919 1354 559,9 193,5 2800 967 374 424 350 270 SOV-CLRG-4006 150 3919 1354 559,9 193,5 8399 2902 474 624 350 330 SOV-CLRG-40012 300 3919 1354 559,9 193,5 16797 5804 624 924 350 421 SOV-CLRG-5002 500 50 5114 1733 730,6 247,6 3653 1238 419 469 400 401 SOV-CLRG-5006 150 5114 1733 730,6 247,6 10959 3713 519 669 400 480 SOV-CLRG-50012 300 5114 1733 730,6 247,6 21918 7427 669 969 400 599 SOV-CLRG-6002 600 50 5987 2068 855,3 295,4 4276 1477 429 479 430 474 SOV-CLRG-6006 150 5987 2068 855,3 295,4 12829 4431 529 679 430 565 SOV-CLRG-60012 300 5987 2068 855,3 295,4 25659 8862 679 979 430 701 SOV-CLRG-8002 800 50 8234 2709 1176,3 387,0 5881 1935 484 534 505 741 SOV-CLRG-8006 150 8234 2709 1176,3 387,0 17644 5806 584 734 505 868 SOV-CLRG-80012 300 8234 2709 1176,3 387,0 35288 11611 734 1034 505 1058 SOV-CLRG-10002 1000 50 10260 3792 1465,7 541,7 7329 2709 564 614 560 1062 SOV-CLRG-10006 150 10260 3792 1465,7 541,7 21986 8126 664 814 560 1213 SOV-CLRG-100012 300 10260 3792 1465,7 541,7 43972 16252 814 1114 560 1439
Package and Delivery
1. Out packing: standard export wooden case
2. Inner packing: with careful stretch film+cardboard
3. Lead time: 1~3workdays when products in stock, 7~15workdays when out of stock
4. Delivery time: Prompt delivery
Shipping Methods
1. Light Weight: by international air express, within 3-7days arriving
2. Heavy Weight: by ocean cargo, arriving time depends on your destination port
Our Services
1. Warranty: Replacement request acceptable within one year, repair service assured within three years
2. Customer Service: Questions report responds in 24 hours, and reply in 48 hours.
Our Company
Established in 1995, SOV hydraulic technology company is an professional leading manufacturer of hydraulic tools in China. Such as PLC lifiting systerm, hydraulic cylinders, torque wrench, nut splitter, flange spreader, gear pullers, hydraulic pumps and accessories etc.
Our products have been widely sold to Europe, America, South-east Asia and Middle East, and have got high appreciation and trust from all our customers. Whenever you need hydraulic products, please rememmber our company is always your reliable friends.
Our well-equipped facilities and excellent quality control enables us meet customers' satisfaction. Besides,we have gained CE and ISO9001:2008 certificates.
Main Series Products
1.Hydraulic cylinders, jacks (5-3000ton), single acting and double acting, hollow plunger; Low height, ultra pressure, lock nut;
2.Hydraulic torque wrench, electric torque wrench, pneumatic torque wrench (100-160000Nm);
3.Hydraulic bolt tensioner (M24-M600); Hydraulic pullers;
4.Hydraulic pumps, manual and electric type (max up to 4000bar);
5.Integrated hydraulic lifting system solutions ( 4-99 points lifting system for house translation or leveling, bridge supporting and tank welding supporting)
6.Hydraulic nut and couplings. (M50-Tr1000), hydraulic hose
Our products have been widely used in industrial field such as steel plant, cement industry, chemical and refinery, bridge, railway construction and maintenance.
Why Choose SOV?
1. Various style for completely series hydraulic products for you to choose.
2. High quality with competitive price.
3. SOV hydraulic technology factory are produced in modern facilities using advantage processing technology. All SOV products meet or exceed CE and ISO standards and tolerances.
4. Quality emphasis in all production processes coupled with 100% inspection for critical performance characteristics ensure product consistency.
5. Our products have been widely used in industrial field such as steel plant, cement industry, chemical and refinery, bridge, railway construction and maintenance.
6. If you have a lifting problem that others can't solve call SOV, the hydraulic tools supplier you need.
