1ton High Strength Hand Tools of Chain Hoist (K1219)
Baoding Jiazhong Hoisting Machinery Plant- Application：Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
- Type：Chain Hoist
- Sling Type：Chain
- Lift Speed：2~8m,min
- Maximum Lifting Height：12m
- Chain Falls：2
Base Info
- Model NO.：K1219
- Certification：CE, ISO9001:2000, GS
- Condition：New
- Color：Orange
- Capacity：1 T 2 T 3 T 5 T 10 T 15 T 20 T 30 T
- Lifting Height：3 M 6m 9 M 12m
- Colour：Yellow
- Chain：G80
- Model：1ton High Strength Hand Tools of Chain Hoist(K1219
- Transport Package：Carton
- Specification：CE ISO9001 GS
- Trademark：HAIYAN
- Origin：China
- HS Code：8425190000
- Production Capacity：1000PCS,Week
Description
Product Description
CB Our Advantages FAQCapacity (ton) 0.25 0.5 1 1.5 2 3 5 7.5 10 Standard lifting height (m) 2.5 2.5 2.5 2.5 2.5 3 3 3 3 Running Test Load (ton) 0.3125 0.625 1.25 1.875 2.5 3.75 6.25 9.375 12.5 Headroon H (mm) 280 345 376 442 470 548 688 765 765 Load Chain Dia.(mm) Columns 1 1 1 1 1 1 2 3 4 Dia+Pitch 4×12 5×15 6×18 7×21 8×24 10×28 9×27 9×27 9×27 Effort to required to lifi max.load (N) 226 235 245 255 324 363 353 373 380 Dimension (mm) A 121 148 172 196 210 255 280 433 463 B 114 132 151 173 175 205 189 189 189 C 24 25 30 33 35 40 42 56 56 D 31 31.5 37.5 42.5 45 50 53 85 85 Net Weight (kg) 6.5 9.3 12.2 16.5 19.5 32 41.1 61.6 75.7 Paching Measurements (lxwxh) (mm) 23×16×15 30×17×18 32×18×19 37×20×24 37×20×24 43×40×30 47×44×35.5 62×47×39.5 53×51×46.5 Extra Weight per meter of extre lift (kg) 0.81 1 1.29 1.61 1.92 2.68 4.1 6.86H 7.73
