• Model NO.：SJG0.3-14
• Feature：Explosion-Proof
• Certification：GS, CE, ISO 9001
• Mobile：4 Wheels
• Lift System：Hydraulic Lift Table
• Type：Mobile Scissor Lift
• Voltage：110V 220V 240V 380V Optional
• Platform：Anti-Skid Checkered Plate
• Material：High Strength Manganese Steel
• Safe Device：Explosion-Proof Lock Valve
• Transport Package：Iron Case or Plywood Case Package
• Trademark：SDLIFT
• Origin：Shandong China
• HS Code：84289090
• Production Capacity：5000 Set Per Year

Model

Capacity

Table   size

Max   height

Work   height

Total   dimension

Net   weigh

SJY0.3-8

300Kgs

2550×1500mm

12m

13.7m

3150×1860×2850mm

2580Kgs

Feature:

1. Lift height: 4-18m
2. Loading capacity: 300-1000kg
3. Easy operation, low maintenance
4. ISO/CE. Platform size: 3230*1600m
5. When the electricity is available, usually for Indoor use
6. Voltage: 110V, 220V, 380V, 415V
7. Longer use time
8. Scaffolding lift control system on the platform and on the down place.
9. Electric scissor lift with 24V battery voltage, keeping staff safety.
10. Emergency Decending Button: Although suddenly power off, the button will guarantee the staff getting down safely.

	1. Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2. The small solid rubber wheels moves slightly,and it has no any damage to the floor.
	3. Supporting legs

Safety :

1) The safety rails to guarantee safety of the people above work platform.

2) The limit switch system helps the work lifts to stop at accurate position.

3) Electricity leakage protection device is equipped on, all electric components are CE certified.

4) All the work lifts are passed 1.2 times loading test before leaving factory.

Package :
