Post Tension Mono Prestressed Cable Jack
Zhengzhou Lead Equipment Co., Ltd.- Type:Hydraulic Jack
- Structure:Hydraulic Jack
- Capacity (Load):27 Tons
- Power Source:Electric
- Max Height:>400mm
- Certification:CE, ISO 9001:2000
Base Info
- Model NO.:QYC series of stressing jack
- Condition:New
- Color:White, Green, Natural,Red, or According to Your Re
- Mating Oil Pump:Ybz2X2-50A(50mpa), Ybz2X1.5-63(63mpa) Oil Pump
- Capacity(Load):<50t
- Apply:Concrete Anchor
- Material:Alloy Steel, Casting Iron, Steel , Plastic
- Shape:Long Round
- Performance:Good
- Operation:Simple and Convenient
- Custom-Made:Can Be Custom-Made
- Occasion:Bridges, High Buildings, Railway and Subway .
- Transport Package:Standard Export Package with Ply Wooden Case
- Specification:CE and ISO certificate
- Trademark:Leadcrete
- Origin:Henan, China(Mainland)
- HS Code:84254210
- Production Capacity:1000 Sets Per Month
Description
Parameter table of QYC front-end fixed jack Model Nominal
tensionin Diameter of
minimum
centre hole Area of
stressing
cylinder Stroke of
stressing Rated oil pressure Overall
dimension Minimum
working
space(mm) The reserved
length
of strand KN mm mm² mm Mpa out dianeter(mm) length(mm) L E mm QYC70 74 10 1437 150 50 63 296 616 54 120 QYC240 240 18 4009 200 60 102 425 825 86.7 200 QYC270 270 18 4415 200 61 105 427 827 89 200 QYC1100 1100 22619 200 49 265 336 QYC2000 2000 42332 200 48 355 386 QYC3000 3000 61575 180 49 415 402
tensionin
minimum
centre hole
stressing
cylinder
stressing
dimension
working
space(mm)
length
of strand
