Platform Workshop Hydraulic Stationary Electric Scissor Lift
Changzhou Cheeson Machinery Co., Ltd.- After-sales Service：Video Technical Support
- Warranty：One Year
- Application：Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
- Lift Mechanism：Scissor Lift
- Carrying Capacity：Light Level
- Moves：Stationary
Base Info
- Model NO.：HW
- Driven Type：Hydraulic
- Running Mode：Stationary
- Feature：Insulating
- Certification：CE
- Transport Package：Wooden Box
- Specification：Electric scissor lift table
- Trademark：CHEESON
- Origin：China
- HS Code：8427109000
- Production Capacity：5000sets,Year
Description
modelrated load Minimum/maximum height
of mesa Mesa dimension base size Hoisting time power supply parameters net weight kg mm mm mm s V/Hz kg MJ-A1001 1000 205/990 820×1300 640×1240 20-25 380/50 160 MJ-A1002 1000 205/990 1000×1600 640×1240 20-25 380/50 186 MJ-A1003 1000 240/1300 850×1700 640×1580 30-35 380/50 200 MJ-A1004 1000 240/1300 1000×1700 640×1580 30-35 380/50 210 MJ-A1005 1000 240/1300 850×2000 640×1580 30-35 380/50 212 MJ-A1006 1000 240/1300 1000×2000 640×1580 30-35 380/50 223 MJ-A2001 2000 230/1000 850×1300 785×1220 20-25 380/50 235 MJ-A2002 2000 230/1000 1000×1600 785×1220 20-25 380/50 268 MJ-A2003 2000 250/1300 850×1700 785×1600 25-35 380/50 289 MJ-A2004 2000 250/1300 1000×1700 785×1600 25-35 380/50 300 MJ-A2005 2000 250/1300 850×2000 785×1600 25-35 380/50 300 MJ-A2006 2000 250/1300 1000×2000 785×1600 25-35 380/50 315 MJ-A4001 4000 240/1050 1200×1700 900×1600 30-40 380/50 375 MJ-A4002 4000 240/1050 1200×2000 900×1600 30-40 380/50 405 MJ-A4003 4000 300/1400 1000×2000 900×2000 45-50 380/50 470 MJ-A4004 4000 300/1400 1200×2000 900×2000 45-50 380/50 490 MJ-A4005 4000 300/1400 1000×2200 900×2000 45-50 380/50 480 MJ-A4006 4000 300/1400 1200×2200 900×2000 45-50 380/50 505
of mesa
