• Model NO.：SY5090SCQZ
• Max Working Radius：9400 mm (Without Jib)
• Crane Color：Optional
• Transport Package：Bulk-Cargo Shipping , RO-RO Shipping , Container
• Specification：3 ton = 3000 kg
• Trademark：SUNY
• Origin：China
• HS Code：843131009
• Production Capacity：1000 Units Per Year

Knuckle Crane model: SYSQ3.2ZA2 ( 3.2 ton, 3 arms)Max lifting Moment6.8 Ton.MSlewing speed< 3 R/minMax lifting capacity3200 KgOil tank capacity60 LMax working radius2100 / 9400 mmRecommended power14 KwHydraulic rated pressure25 MpaInstallation space1150 mmHydraulic flow25 L/minOuttrigger span 2234~3514 mmSlewing angle400° slew angleCrane self weight850 KgSlewing capacity 4°Optional manual jib work radius Nil.Optional: Remote control ; Extral beam; Rated capacity limited; Cooler.

Following is the mainly specification of 4*2 truck mounted crane for reference.more details parameters of truck mounted crane, please touch with S.K.Y.P.E - ZengertruckVehicle modelSY5090SCQZ I-S-U-Z-U 4X2 truck mounted craneChassis modelQL10909Cab innerI-S-U-Z-U 2015 new standard cab, one row seat, opting air conditioner. .Overall dimension 6200/7600*2260*3300 mm (height without crane)Cargo dimensions3100/4500*2150*400 mm (this length after equipped with crane)Cargo materialCarbon steel, side 2 mm, board 3 mm.GVW9995 kgCurb weight3800 kg (without crane weight)Rated load8000 kgTraction4x2Wheel base3815 mmTire / quantity8.25-26, 6+1 pcs (nylon tire)TransmissionMLD, Mechanical 6 forward + 1 reverseEngine4HKQ-TCG40 (EURO 4 emission)Horse power / Exhaust190 hp (139 kw), 5193 ml exhaust.
we can customize all kinds of truck & trailer in accordance with customer's requirement.

We warmly welcome you to our factory for inspection.
We also produce other different kinds of special automobile.
