CE Verified 500 Kg 1 Ton 2 Ton 3 Ton 5 Ton High Performance Monorail Low Headroom Electric Chain Hoist with Motorized Trolley for Overhead Crane Girder & I Beam

Nucleon (Xinxiang) Crane Co., Ltd.
  • After-sales Service：Technical Advisory of Installation & Commissioning
  • Warranty：12 Month Warranty After Successful Installation
  • Application：Double Beam Crane, Gantry Crane, Bridge Crane, Single Grinder Crane, Lifting Platform, Small Crane
  • Type：Chain Hoist
  • Sling Type：Chain
  • Lift Speed：2~8m,min

Base Info

  • Model NO.：NL
  • Maximum Lifting Height：8 M
  • Chain Falls：1
  • Certification：CE, ISO9001:2015
  • Condition：New
  • Color：Black
  • Load Capacity：250 Kg - 5 Ton
  • Beam Width：50~180 mm
  • Height of Lift：up to 8 Meters
  • Control：Radio Remote,Pendant Control
  • Chain Type：G80 Grade DIN
  • Power Supply：220~480V, 50~60Hz, DC,AC
  • Hoisting Speed：2.5,10 M,Min
  • Hoist Travel Speed：5.0,15 M,Min (Motorized Trolley)
  • Duty Class：up to A4 (ISO)
  • Applications：I-Beam,Monorail Bridge Beam,Box Girder
  • Installation：Video Tutorial, Site Installation & Commissioning
  • Random Files：Operation & Maintenance Manual, Wiring Diagram
  • Spare Parts：Provide Random Spares for Two Year Maintenance
  • Delivery：Within 15 Days
  • Transport Package：Carton,Wooden Case,Iron Case
  • Specification：Fix Stand,Manual Trolley,Motorized Trolley
  • Trademark：Nucleon Crane
  • Origin：Henan, China
  • HS Code：8425110000
  • Production Capacity：10000 Sets Per Annum

Description

Basic Info.

Model NO. NL Maximum Lifting Height 8 M Chain Falls 1 Certification CE, ISO9001:2015 Condition New Color Black Load Capacity 250 Kg - 5 Ton Beam Width 50~180 mm Height of Lift up to 8 Meters Control Radio Remote/Pendant Control Chain Type G80 Grade DIN Power Supply 220~480V, 50~60Hz, DC/AC Hoisting Speed 2.5/10 M/Min Hoist Travel Speed 5.0/15 M/Min (Motorized Trolley) Duty Class up to A4 (ISO) Applications I-Beam/Monorail Bridge Beam/Box Girder Installation Video Tutorial, Site Installation & Commissioning Random Files Operation & Maintenance Manual, Wiring Diagram Spare Parts Provide Random Spares for Two Year Maintenance Delivery Within 15 Days Transport Package Carton/Wooden Case/Iron Case Specification Fix Stand/Manual Trolley/Motorized Trolley Trademark Nucleon Crane Origin Henan, China HS Code 8425110000 Production Capacity 10000 Sets Per Annum

Product Description

CE Verified 500 Kg 1 Ton 2 Ton 3 Ton 5 Ton High Performance Monorail Low Headroom Electric Chain Hoist with Motorized Trolley for Overhead Crane Girder & I BeamCE Verified 500 Kg 1 Ton 2 Ton 3 Ton 5 Ton High Performance Monorail Low Headroom Electric Chain Hoist with Motorized Trolley for Overhead Crane Girder & I BeamCE Verified 500 Kg 1 Ton 2 Ton 3 Ton 5 Ton High Performance Monorail Low Headroom Electric Chain Hoist with Motorized Trolley for Overhead Crane Girder & I Beam
CE Verified 500 Kg 1 Ton 2 Ton 3 Ton 5 Ton High Performance Monorail Low Headroom Electric Chain Hoist with Motorized Trolley for Overhead Crane Girder & I Beam


CE Verified 500 Kg 1 Ton 2 Ton 3 Ton 5 Ton High Performance Monorail Low Headroom Electric Chain Hoist with Motorized Trolley for Overhead Crane Girder & I Beam
1. Technical advisory of the best material handling solution before sale to maximize efficiency while optimize investment plan on the other hand through our 30 years dedications to lifting performance.

2. Installation service of overhead crane available with:
Video tutorial support for whole installation process.
7/24 remote assistance for crane installation guidance and commissioning.
Field engineer service of installation, commissioning and training.

3. Twelve months warranty after successful crane commissioning.

4. Annual inspection service at customer's site.
