• Model NO.：JM
• Running Mode：Moving
• Feature：Antiseptic
• Standard：National Standards, Nonstandard
• GB/T 24001-2004 Idt ISO14001: 2004：Pass
• Sandblast：Could Supply
• GB/T 19001-2000 Idt ISO 9001: 2000：Pass
• Painting Color：According to Your Demand
• GB/T 28001-2001, Ohsas18001: 1999：Pass
• Industrial Voltage：According to Your Demand
• Structure：Hook Crane
• Installation：Truck Crane
• Type of Work：Weight Level
• Application：Goods Yard Crane
• Transport Package：Packed by Plywood Crate All by Export Standard
• Specification：China National standard
• Trademark：KUANGYUAN
• Origin：China
• HS Code：84251100
• Production Capacity：28, 000 Sets,Year

Basic Info.

Model NO. JM Running Mode Moving Feature Antiseptic Standard National Standards, Nonstandard GB/T 24001-2004 Idt ISO14001: 2004 Pass Sandblast Could Supply GB/T 19001-2000 Idt ISO 9001: 2000 Pass Painting Color According to Your Demand GB/T 28001-2001, Ohsas18001: 1999 Pass Industrial Voltage According to Your Demand Structure Hook Crane Installation Truck Crane Type of Work Weight Level Application Goods Yard Crane Transport Package Packed by Plywood Crate All by Export Standard Specification China National standard Trademark KUANGYUAN Origin China HS Code 84251100 Production Capacity 28, 000 Sets/Year

Product Description

Slow Speed Electric Winch 3ton

Wirerope Electric winch is one type of electric winch with wirerope as the hoisting rope, the electric winch have many series, for intance, it could be called JM and JK on the hoisting speed, it could be called double hook or single hook base on the hoisting hook, it could be called friction winch and normal winch base on the friction exist or not!
Mainly, there are two type in this series, small pull capacity and large pull capacity. Large pull capacity mostly are applicable to port building, traction of shipyard, steel structure transport and assemble, disassemble, pulling machines. Its feature is that line rope pull large, sometimes with rope guider for wire rope dispose trimly, safety and credible. Small pull capacity mostly are applicable for construction, lifting, disassembly, traction, assembly in construction company, mine, factory and so on.

Customer Care:

Our philosophy is that the customer should be happy with the system performance and enormous Improvement in work environment and also reduction of labour inputs for eternity working together With customer and ensuring that the work is executed to the utmost satisfaction of the customer.

We concentrate to have positive and flexible approach towards customer need through its comprehensive solution and service capabilities, professionally and cost effectively. As a company whose success derives from mains fully committed to develop close working partnership with its customer.

Type	Speed	Rope diameter	Motor type	Motor power	Dimension	Weight
JK0.5	22 m/min	7.5	Y100L2-4	3kw	710*690*490	200kg
JK1	22 m/min	9.3	Y112M-4	4kw	710*610*410	300kg
JK1.6	24 m/min	12.5	Y132S-4	5.5kw	940*900*570	500kg
JK2	24 m/min	13	Y132M-4	7.5kw	940*900*570	550kg
JK3.2	30 m/min	15.5	YZR180L-6	15kw	1640*1430*820	1150kf
JK5	30 m/min	21.5	YZR225M-6	30kw	1900*1738*985	2500kg
JK8	30 m/min	26	YZR280S-8	45kw	1980*1790*1100	3500kg
JK10	30 m/min	30	YZR315S-8	55kw	2250*2500*1300	5100kg
