Ini 150kn 15 Ton Single Drum Electric Mooring Winch

INI HYDRAULIC CO., LTD.
  • Type：Electric Winch
  • Driven Type：Hydraulic
  • Speed：Fast
  • Carrying Capacity：Special Weight Level
  • Tonnage：30T
  • Reel Number：2

Base Info

  • Model NO.：INI 150kN
  • Running Mode：Haulage
  • Feature：Antiseptic, Insulating, Explosion-Proof
  • Certification：GS, CE, RoHS, ISO 9001
  • Standard：National Standards, Nonstandard
  • Model Number：Isyj Series Recovery Winch
  • Capacity：30 Ton
  • Third Party Inspection：Available
  • Clutch：Manual or Hydraulic
  • Power Source：Hydraulic
  • Brand Name：Ini
  • Place of Origin：Zhejiang, China (Mainland)
  • Packaging Details：Standard Seaworthy Packing
  • HS Code：84253990, 84253990
  • Pull Direction：Backward
  • Transport Package：Standard Seaworthy Packing
  • Specification：OEM
  • Trademark：INI
  • Origin：Zhejiang
  • Production Capacity：150 Piece,Pieces Per Month

Description

Rated line pull (1st layer)KN / kgs / lbs39/ 4000 / 9000Motor displacementml/rev80Oil flowL/min15-60Oil pressureMPa14Gear ratio 23:1Wire rope (diameter x length) Φ11mm x 25metreDrum dimensions (diameter x length)mmΦ88 xΦ192 x 200Mounting dimension and bolts 300mm x 280mm 8-M12Overall dimensionmm516(524) x 316(376) x 237Net weight (with wire rope and hook)kg48
Line pull, oil pressure and oil flow, line speed
 Line pull (KN)Oil pressure (Mpa)Oil flow (L/min)Speed (m/min)03.5152.5278.5254.03611.0406.53914.0508.04915.0609.5
Layer of calbe, line pull per layer, speed and wire rope capacity
 Layer of cableLine pull (KN)Speed (m/min)Wire rope capacity1399.5523411.81232813.91942516.025

  •  CertificationIni 150kn 15 Ton Single Drum Electric Mooring Winch
