Stationary Electric Single Scissor Lift Table (HL-W SERIES)
Leeda Global Co., Ltd.- Application：Lift Table
- Lift Mechanism：Scissor Lift
- Carrying Capacity：Middle-Level
- Moves：Stationary
- Driven Type：AC
- Running Mode：Stationary
Base Info
- Model NO.：HL-W SERIES
- Certification：GS, CE, ISO 9001
- Design：Heavy Duty Type
- Capacity：1 Ton ~8 Ton
- Min Height：205 mm
- Raised Height：1400 mm
- Platform Size：Max: 2200X1800mm
- Power Pack：380V,50Hz,AC Vesrion
- Transport Package：Wooden Pallet
- Specification：Max 8 ton
- Trademark：Leeda
- Origin：China
- HS Code：8427900
Description
ModelCapacity Lowered Height Raised Height Platform Size Base Frame Size Lift Time Power Pack Net Weight (kg) (mm) (mm) (mm) (mm) (second) (kg) HL-W1001 1000 205 990 820× 1300 640× 1240 20-25 380V/50HZ, AC 1.1kw 160 HL-W1002 1000 205 990 1000× 1600 640× 1240 20-25 186 HL-W1003 1000 240 1300 850× 1700 640× 1580 30-35 200 HL-W1004 1000 240 1300 1000× 1700 640× 1580 30-35 210 HL-W1005 1000 240 1300 850× 2000 640× 1580 30-35 212 HL-W1006 1000 240 1300 1000× 2000 640× 1580 30-35 223 HL-W1007 1000 240 1300 1700× 1500 1580× 1320 30-40 380V/50HZ, AC 1.1kw 365 HL-W1008 1000 240 1300 2000× 1700 1580× 1320 30-40 430 HL-W2001 2000 230 1000 850× 1300 785× 1220 20-25 380V/50HZ, AC 2.2kw 235 HL-W2002 2000 230 1000 1000× 1600 785× 1220 20-25 268 HL-W2003 2000 250 1300 850× 1700 785× 1600 25-35 289 HL-W2004 2000 250 1300 1000× 1700 785× 1600 25-35 300 HL-W2005 2000 250 1300 850× 2000 785× 1600 25-35 300 HL-W2006 2000 250 1300 1000× 2000 785× 1600 25-35 380V/50HZ, AC 1.5kw 315 HL-W2007 2000 250 1400 1700× 1500 1600× 1435 25-35 380V/50HZ, AC 2.2kw 415 HL-W2008 2000 250 1400 2000× 1800 1600× 1435 25-35 500 HL-W4001 4000 240 1050 1200× 1700 900× 1600 30-40 375 HL-W4002 4000 240 1050 1200× 2000 900× 1600 30-40 405 HL-W4003 4000 300 1400 1000× 2000 900× 2000 45-50 470 HL-W4004 4000 300 1400 1200× 2000 900× 2000 45-50 490 HL-W4005 4000 300 1400 1000× 2200 900× 2000 45-50 480 HL-W4006 4000 300 1400 1200× 2200 900× 2000 45-50 380V/50HZ, AC 2.2kw 505 HL-W4007 4000 350 1300 1700× 1500 1620× 1400 35-45 380V/50HZ, AC 2.2kw 570 HL-W4008 4000 350 1300 2200× 1800 1620× 1400 35-45 655
