Self-Propelled Economical Scissor Lift with Max Platform (6m)

Boonai (Suzhou) Lift Equipment Co., Ltd.
  • Application：Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane, Decoration
  • Lift Mechanism：Scissor Lift
  • Carrying Capacity：Middle-Level
  • Moves：Moving
  • Driven Type：DC or AC, DC and AC
  • Running Mode：Moving

Base Info

  • Model NO.：SJY0.45-6
  • Feature：Explosion-Proof, Insulating, Travel Device, Pressure Control System
  • Certification：CE, ISO 9001, QC Issued by Gov.
  • Delivery：15 Days, or Rushed as Required
  • Warranty：12 Months, Apart From Man-Made Fault
  • Max Platform Height (mm)：6000
  • Max Working Height (mm)：7700
  • Platform Size (mm)：1850*880
  • Rated Load (Kg)：450
  • Lifting Time (S)：54
  • Voltage (V/Hz)：380,50
  • Travel Motor Power (Kw)：0.75
  • Motor Power (Kw)：1.1
  • Transport Package：Steel Pallet+Buffer Sponge+Bubble Bag+Waterproof
  • Specification：720 KG
  • Trademark：Boonai
  • Origin：Xiangcheng District, Suzhou, China
  • HS Code：8428909090
  • Production Capacity：200 Units Per Month

Description

ParametersModelSJY0.45-6SJY0.45-7.5SJY0.45-9SJY0.45-11SJY0.45-12SJY0.45-14SJY0.45-16Max Platform height(mm)60007500900011000120001400016000Min Platform height(mm)980125015001600170018001980Platform Size(mm)1800*9001800*10001800*10002100*11502450*13502450*13502800*1500Rated Load(kg)450450450450450450450Lifting times(s)5472838890120145Voltage(V/Hz)380/50380/50380/50380/50380/50380/50380/50Motor Power(Kw)1.51.52.23345Overall length (mm)2000200020002250260026002950Overall width (mm)1080120012001350155015501750Overall height (mm)980125015001600160018002180Extended outrigger size(mm)600700700700700800850Over weight(kg)650110012601380185025002700


Self-Propelled Economical Scissor Lift with Max Platform (6m)

• Company Certificates
Self-Propelled Economical Scissor Lift with Max Platform (6m)

• Part or Customers
Self-Propelled Economical Scissor Lift with Max Platform (6m)

• Packing
Self-Propelled Economical Scissor Lift with Max Platform (6m)

• Warranty
1. User-friendly English manual for machine using and maintenance.
2. One year warranty for whole machine without man-made fault.
3. We will send you parts for free if there are any non-human factors problem during
warranty time.
4. 24-hours technical support by email, telephone or other communication online.
5. We could reply you in 2 hours after received your any questions even on weekend and
holidaysm engineers are available to your company if necessary.
