• Model NO.：QUY80
• Engine Power：200 Kw
• Fixed Jib Length：9-18 M
• Gross Vehicle Mass：28 T
• Warranty：1 Year
• Transport Package：Nude Package
• Specification：ISO, CE, GOST
• Trademark：Oriemac
• Origin：Jiangsu, China(Mainland)
• HS Code：84295212
• Production Capacity：800PCS,Month

Basic Info.

Model NO. QUY80 Engine Power 200 Kw Fixed Jib Length 9-18 M Gross Vehicle Mass 28 T Warranty 1 Year Transport Package Nude Package Specification ISO, CE, GOST Trademark Oriemac Origin Jiangsu, China(Mainland) HS Code 84295212 Production Capacity 800PCS/Month

Product Description

Top Brand New 80 Tons Crawler Crane QUY80 for Sale

1. Safety control system:
Two convenient and reliable modes of operation; Working and installation, with real-time level display, stop operation braking away from machine, electrical emergency control, anti-lightning protection, automatically walk switches, CCTV monitoring function, complete safety and supervision system;
2. Excellent operating performance:
Advanced load-sensing, limit load regulation and electrohydraulic proportional micro-speed control make each micro-movement extremely good and operation more stable;
3. Reliable function assurance:
Key components adopt famous international brands; Sufficient safety margin for structural and mechanical design; Control system can operate stably in harsh environments such as cold, high temperature, altitude and sandy conditions;
4. Convenient maintenance technology:
It takes approximately no more than 10min/person to adjust; No more than 30min/per son for dai ly maintenance; No more than 2h/person to repair. GPS remote monitoring system is optional for maintenance and management;
5. Powerful lifting capacity:
The maximum lifting capacity of boom is 50t× 3.7m=185t· M, and the max. Length of main boom is 52m;
6. Flexible configuration combination:
Free hook is optional;
7. Large-chassis design:
Track frame which can be broadened, ensuring excellent machine and job stability within the range of 360 ° Rotation;
8. Optimized transportation programs:
With the function of crawler frame telescopic function, the max. Transportation width of the whole machine is 3.36m;
9. Two counterweight configurations:
Improve the lifting capacity of medium and long boom.


Item	Unit	Parameter
		80
Max.load moment	kN.m	3375
Boom length	m	13-58
Elevation angle	°	30-80
Main winch system	m/min	0-120
Aux.winch system	m/min	0-120
Elevating system	m/min	0-57
Grade-ability		30%
Swing speed	r/min	0-2
Max. travel speed	km/h	0-1.2
Mean ground pressure	MPa	0.087
Engine output	KW	200
Jib length	m	9-18
Jib erection angle	°	10/30
Max. weight of single part in transport state	t	28
Dimension of single part(main machine) in transport state(L×W×H)	m	7.8×3.4×3.1
