• Model NO.：XGS34
• Driven Type：Hydraulic
• Running Mode：Moving
• Feature：Explosion-Proof, Insulating
• Certification：GS, CE, RoHS, ISO 9001
• Model：Xgs34
• Weight：18400kg
• Engine：Perkis
• Traveling Motor：Danfos,Sunbun
• Maximum Working Range：24.6m
• Maximum Load Capacity：230kg
• Platform Size：2400*900mm
• Maximum Travel Speed：5km,H
• Transport Package：40′hq Container
• Specification：CE, ISO
• Trademark：ORIEMAC
• Origin：Jiangsu, China
• Production Capacity：1000unit,Month

Basic Info.

Model NO. XGS34 Driven Type Hydraulic Running Mode Moving Feature Explosion-Proof, Insulating Certification GS, CE, RoHS, ISO 9001 Model Xgs34 Weight 18400kg Engine Perkis Traveling Motor Danfos/Sunbun Maximum Working Range 24.6m Maximum Load Capacity 230kg Platform Size 2400*900mm Maximum Travel Speed 5km/H Transport Package 40′hq Container Specification CE, ISO Trademark ORIEMAC Origin Jiangsu, China Production Capacity 1000unit/Month

Product Description

ORIEMAC Official XGS34 34m New Telescopic Straight Arm Aerial Working Platform Boom Lift for Sale

Official XGS34 34m new telescopic straight arm platform boom lift.

Official XGS34 34m new telescopic straight arm platform boom lift has electronic control turning, wide foam tires, excellent climbing driving, adaptive to various complicated road conditions; dual loading operation curves for real-time loading control; the widest operation reach of proucts of the same class.

Official XGS34 34m new telescopic straight arm platform boom lift meets demands of users from building construction, bridge and equipment maintenance, shipyard and petrochemical industry.

Advantages and features:

1. Official XGS34 34m new telescopic straight arm platform boom lift is the widest of the products of the same class, which improves the operation capacity; Strong driving capacity, grade ability up to 45%.

2. Enabling aerial work platform XGS34 to incomparably move in any complicated site.

3. Real-time monitor the load, effectively making use of boom and making its work performance at leading edge.

4. Specific human-machine interactive system, forming a perfect safety protection system.

III. Configuration of XGA26 Main Parts

Item	Unit	Parameter
Overall length of complete machine	mm	14300
Overall width (With shaft retracted/extended)	mm	2490/3800
Overall height	mm	3070
Wheelbase	mm	3800
Max. working height	m	34.2
Max. platform height	m	32.2
Max. working range	m	24.6
Max. load capacity	kg	230 (unrestricted)/340 (restricted)
Luffing range of boom	°	-6 ~ +75
Slewing angle of turntable	°	360°
Max. rearward slewing (With shaft retracted/extended)	mm	2085/1430
Dimension of platform	mm	2400×900
Slewing angle of platform	°	160
Overall weight	kg	18400
Max. traveling speed	km/h	5
Min. turning radius (axle retracted/extended)	m	8.2/10.8 (Two-wheel steering) 5.8/6.8 (Four-wheel steering)
Min. ground clearance	mm	260
Max. gradeability	%	45
Specification of tire	-	385/65D22.5
Engine model	-	Perkis 1104D-44T
Engine rated power	kW/(r/min)	55.5/(2400)

IV.Main Technical Specification of XGA26
