• Model NO.：QUY55
• Specification：CE
• Origin：Jiangsu, China
• HS Code：84264910
• Production Capacity：30 Sets,Month

ItemValueRemarksMax. lifting capacity × Radiust × m55× 3.7 Deadweight with basic boomt48 Main boom lengthm13~52 Fixed jib lengthm6~15 Max. lifting capacity of fixed jibt5 Offset angle of fixed jib°10, 30 Max. length of main boom with fixed jibm43+15 Max. speed of single rope on drumMain winchm/min120The 4 th rope layerAuxiliary winchm/min120The 4 th rope layerDerricking winchm/min60The 4 th rope layerSlewing speedrpm0~3.0 Traveling speedkm/h0~1.6 Gradeability%40 Ground pressureMPa0.066 Overall dimensions (LxWxH)mm6800x3300x3020 EngineRated power/ rotational speedkW/rpm132/2200 Max. output torque/ rotational speedNm/rpm750/1300 Emission standardEU Stage III Crawler gauge × ground contact length  x track shoe widthmm2540x4700x760Crawler carrier retracted3540x4700x760Crawler carrier extended


Lifting Capacity Table of Main Boom

Boom length(m)	13	16	19	22	25	28	31	34	37	40	43	46	49	52
Falls	10	10	8	6	5	5	5	3	3	3	3	2	2	2
Radius(m)
3.7	55
4	49.5	47.3
4.5	41	40.1	38.5
5	34.3	34.2	33.7	32
5.5	29.5	29.4	29.3	29.1	27.5
6	25.8	25.8	25.6	25.5	25.4	24.2
7	20.6	20.6	20.4	20.4	20.3	20.2	20
8	17.1	17.5	16.8	16.8	16.8	16.6	16.6	16.4	16.2
9	14.6	14.5	14.5	14.3	14.2	14.1	14.0	13.75	13.6	13.4	13.2
10	12.7	12.55	12.5	12.3	12.3	12.2	12.1	12	11.8	11.5	11.3	11.1	11.0	10.3
12	10	9.8	9.8	9.6	9.5	9.58	9.45	9.2	9	8.8	8.7	8.5	8.4	8.3
14		8.1	8.1	8	7.8	7.7	7.6	7.4	7.2	7.0	6.85	6.7	6.6	6.5
16			6.8	6.5	6.4	6.35	6.3	6.1	5.9	5.7	5.6	5.5	5.4	5.2
18				5.7	5.5	5.35	5.3	5.1	4.9	4.7	4.6	4.4	4.3	4.2
20				4.9	4.6	4.6	4.5	4.3	4.2	4	3.9	3.7	3.6	3.5
22					4.0	4.0	3.9	3.7	3.6	3.4	3.3	3.1	3	2.85
24						3.5	3.4	3.2	3.1	2.9	2.8	2.6	2.5	2.4
26							2.9	2.8	2.6	2.45	2.3	2.15	1.9	1.9
28								2.4	2.3	2.1	2	1.8	1.7	1.6
30								2.1	1.95	1.8	1.7	1.5	1.4	1.3
32									1.68	1.5	1.4	1.25	1.2	1
34										1.3	1.2	1.1	1	0.8
