• Model NO.：NH
• Certification：CE
• Condition：New
• Color：According to Your Demand
• Working Class：Reach to A6
• Max Capacity for Single Beam：20t
• Max Capacity for Double Beam：80t
• Hoisting Height：6,9,12,18m
• Traveling Speed：5~20m,Min
• Safety Devices：Wireless Anti-Collision Limiter
• Safety Features：Braking Security Protection,Anti- Collision Sweep
• Motor：Imported From German
• Reducer：Imported From German
• Operation：Safe and Reliable, Exact Poistioning
• Transport Package：High Quality Plywood Crate
• Specification：China National standard
• Trademark：KY
• Origin：China
• HS Code：84261990
• Production Capacity：5000 Sets,Year

Basic Info.

Model NO. NH Certification CE Condition New Color According to Your Demand Working Class Reach to A6 Max Capacity for Single Beam 20t Max Capacity for Double Beam 80t Hoisting Height 6/9/12/18m Traveling Speed 5~20m/Min Safety Devices Wireless Anti-Collision Limiter Safety Features Braking Security Protection,Anti- Collision Sweep Motor Imported From German Reducer Imported From German Operation Safe and Reliable, Exact Poistioning Transport Package High Quality Plywood Crate Specification China National standard Trademark KY Origin China HS Code 84261990 Production Capacity 5000 Sets/Year

Product Description

Features:

1. With aluminum alloy shell of reducer
2. Steady running and low noise
3. Lifetime lubricating (within safety service circle).
4. Double-disk electromagnetic brake

Semi-European electric hoist series wire rope electric hoist, designed and developed by ourselves, is a new kind of low headroom product. According to Europe standard of FEM and DIN, the product is researched and developed at the basis of general planning the lift capacity, basic structure, mechanism working system and performance parameters, and modular design idea.
It employ motor of hoisting mechanism and reducer imported from Germany. The integrated and compact design of hoisting motor, reducer, reel and limit switch saves space for the user. Modular design increases the reliability of mechanism meanwhile reduces the time and cost for maintaining.
It has more and faster hoist speed and various pulley ratio which can be selectrd. The standard traveling mechanism of trolley is controlled by converter, with speed of 20m/min, which makes a little swing and accurate position if hoisting items while trolley traveling as well as lifts precision and valuable items reliably.

S.W.L (KG)	FEM	ISO	Hoist height(m)	Hoist speed(m/min)	Traveling speed(m/min)	Size H (MM)	Size C (mm)
1000	4M	M7	6/9/12/18	0.8/5.0	5~20	232	500
1250	3M	M6	6/9/12/18	0.8/5.0	5~20	232	500
1600	3M	M6	6/9/12/18	0.8/5.0	5~20	232	500
1600	2M	M5	6/9/12/18	1.6/10	5~20	232	500
2000	2M	M5	6/9/12/18	0.8/5.0	5~20	232	500
2000	3M	M6	6/9/12/18	1.3/8.0	5~20	232	500
2500	3M	M6	6/9/12/18	0.8/5.0	5~20	232	500
2500	3M	M6	6/9/12/18	1.0/6.3	5~20	232	500
2500	2M	M5	6/9/12/18	1.6/10	5~20	232	500
3200	2M	M5	6/9/12/18	0.8/5.0	5~20	232	500
3200	2M	M5	6/9/12/18	1.0/6.3	5~20	232	500
3200	1AM	M4	6/9/12/18	1.6/10	5~20	254	590
5000	2M	M5	6/9/12/18	0.8/5.0	5~20	254	590
5000	3M	M6	6/9/12/18	1/6.3	5~20	321	740
5000	2M	M5	6/9/12/18	1.6/10	5~20	321	740
6300	1AM	M4	6/9/12/18	0.8/5.0	5~20	254	590
6300	4M	M7	6/9/12/18	0.8/5.0	5~20	321	740
6300	2M	M5	6/9/12/18	1.3/8.0	5~20	321	740
8000	3M	M6	6/9/12/18	0.8/5.0	5~20	321	740
10000	1AM	M4	6/9/12/18	1.0/6.3	5~20	321	740
10000	2M	M5	6/9/12/18	0.8/5.0	5~20	321	740
10000	3M	M6	6/9/12/18	0.66/4.0	5~20	321	740
12500	1AM	M4	6/9/12/18	0.8/5.0	5~20	321	740
12500	2M	M5	6/9/12/18	0.6/4.0	5~20	321	740
12500	1AM	M4	6/9/12/18	1.0/6.3	5~20	321	740
12500	3M	M3	6/9/12/18	0.6/4.0	5~20	411	850
16000	2M	M5	6/9/12/18	0.6/4.0	5~20	411	850
20000	1AM	M4	6/9/12/18	0.6/4.0	5~20	411	850
