Electric Standard Stationary Large Power Capacity Winch Cheap High Quality

Pingyang Construction Hoisting Machinery Co.
  • Warranty：1year
  • Type：Electric Winch
  • Driven Type：AC
  • Speed：Slow
  • Carrying Capacity：Weight Level
  • Tonnage：5T

Base Info

  • Reel Number：1
  • Running Mode：Stationary
  • Feature：Insulating
  • Certification：ISO 9001
  • Standard：National Standards
  • Lifting Capacity：5ton
  • Motor：ABB or Normal Brand
  • Transport Package：Wooden Case
  • Specification：5ton
  • Trademark：CH
  • Origin：China
  • HS Code：8425319000
  • Production Capacity：100 PCS,Month

Description

ModelJM2JM3JM5JM8JM10Line pull capacity (kg)200030005000800010000average speed (m/min)121010109Wire rope(mm):12.515.521.52630Reduction boxTypeJZQ350JZQ350JZQ400JZQ500JZQ650Transmission ratio23.3431.523.3431.540.17Drum (mm)Diameter/mm273325406500550Length4805206459001000Capacity(m)150180250300450motorTypeYZ160M2-6YZ160M2-6YZ160L-6YZR225M-8YZR250M1-8Power(kW)7.57.5112230Rotate speed(r/min)948948953720720Hydraulic BrakeYWZ-200/25YWZ-200/25YWZ-300/45YWZ-300/45YWZ-300Equipment Dimension (mm)1060x1500x7501600x1100x8201400x1910x9502050x1640x10002470x2280x1180Weight(kg)630680140030004000 Electric Standard Stationary Large Power Capacity Winch Cheap High QualityElectric Standard Stationary Large Power Capacity Winch Cheap High QualityElectric Standard Stationary Large Power Capacity Winch Cheap High QualityElectric Standard Stationary Large Power Capacity Winch Cheap High Quality
