• Model NO.：JCPT1418RT , JCPT1218RT
• Feature：Explosion-Proof, Insulating
• Certification：GS, CE, RoHS, ISO 9001
• Max. Working Height：12-14.3m
• Max. Platform Height：10-12.3m
• Ground Clearance：0.24m
• Wheel Base：2.29m
• Gradeability：40%
• Transport Package：Null
• Specification：3.84*1.76*2.74m
• Trademark：Dingli
• Origin：Zhejiang, China
• HS Code：7616991090
• Production Capacity：1000,Year

ModelJCPT1418RTJCPT1218RTMax. Working Height 14.30m12.00Max. Platform Height 12.30m10.00mOverall Length(With/Without Outriggers) 3.84m/3.19m3.84m/3.19mOverall Width 1.76m1.76mOverall Height(Rails Up)2.74m2.59mOverall Height(Rails Down) 1.97m1.82mPlatform Size(Lenth/Width )2.88m×1.52m2.88m×1.52mPlatform Extension Size 1.43m1.43mGround Clearance0.24m0.24mWheel Base 2.29m2.29m

Performance

ModelJCPT1418RTJCPT1218RTS.W.L363kg454kgS.W.L On Extension136kg136kgMax. Occupants34Turning Radius(Inside/Outside)2.15m/4.85m2.15m/4.85mTravel Speed(Stowed)5.20km/h5.20km/hTravel Speed(Raised)0.48km/h0.48km/hUp/Down Speed45/46sec38/46secGradeability40%40%Max. Working Slope2°/3°2°/3°Tyre26×12-16.526×12-16.5

Power

ModelJCPT1418RT JCPT1218RTEngine    Kubbota D110518.6kw/2400rpm18.6kw/2400rpmHydraulic Tank71L71LDiesel Tank47L47L

Weight

ModelJCPT1418RTJCPT1218RTOverall Weight(With/with Outriggers)5050kg/5050kg4300kg/3900kg
