18-56m Hydraulic Diesel Power Telescopic Boom Lift for Sale
Jinan PLK Machinery Co., Ltd.- After-sales Service：Online Service, Free Express Accessories.
- Warranty：12 Months
- Application：Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
- Lift Mechanism：Hydraulic
- Carrying Capacity：200 Kg
- Moves：Towable
Base Info
- Model NO.：GTDZ
- Driven Type：Hydraulic
- Running Mode：Moving
- Feature：Explosion-Proof, Insulating
- Certification：GS, CE, RoHS, ISO 9001
- Lift Drive：AC,DC,Hydraulic Diesel Ect
- Turning Degree：360degree
- Loading Capacity：Customization
- Surface Treatment：Plastic Spraying
- Color：Red Yellow Blue Customized
- Quality Assured：CE ISO9001 Saco FTA SGS Iam Ect
- Input Voltage：110V 220V 240V 380V, 400V, Customized
- Safety Precaution 1：Aluminum Safety Sensor
- Safety Precaution 2：Anti Explosion Valve
- Safety Precaution 3：Anti Explosion Valve
- Transport Package：Full Container
- Specification：5500*2200*2200
- Trademark：PLK LIFT
- Origin：China
- HS Code：8428909090
- Production Capacity：500 Sets,Month
Description
230kg
Length( stowed)
6.2m
7.7m
8.25m
9.23m
Width (stowed)
2.29m
2.29m
2.35m
2.35m
Height(stowed)
2.38m
2.38m
2.38m
2.39m
Wheel base
2.2m
2.4m
2.6m
2.6m
Ground clearance
430mm
430mm
430mm
430mm
Platform measurement
1.83*0.76*1.13m
1.83*0.76*1.13m
1.83*0.76*1.13m
1.83*0.76*1.13m
Tuning radius (inside)
3.0m
3.0m
3.0m
3.0m
Tuning radius (outside)
5.2m
5.2m
5.2m
5.2m
Travel speed(stowed)
4.2km/h
Travel speed(raised or extended)
1.1km/h
Grade ability
45%
45%
45%
40%
Solid tire
33*12-20
Swing speed
0~0.8rpm
Turntable swing
360° Continuous
Platform leveling
Automatic leveling
Platform rotation
±80°
Hydraulic tank volume
100L
Total weight
7757kg
7877kg
8800kg
9200kg
Control voltage
12V
Drive type
4*4 (All-Wheel-Drive)
Engine
DEUTZ D2011L03i Y(36.3kw/2600rpm)/Yamar(35.5kw/2200rpm)
