• Model NO.：JQHSB50*12
• HS Code：842539
• Production Capacity：500

Basic Info.

Model NO. JQHSB50*12 HS Code 842539 Production Capacity 500

Product Description

Introduction:
The JQHSB50*12 Rotary-base Double-braking Air Winch adopts compressed air as power to drive the TMH17 piston air motor, transferring torque to drum through the second Gear Reducer. By operating manual diversion valve on the motor, the winch can perform hoisting, lowering and stopping actions to the wire rope. Considering security, it is specially designed with hand and foot double manual brakes for fear of unexpected accidents. The Double-braking Air Winch is especially fit for hauling, lifting and other work in mines, construction engineering sites, platforms of oilfields off-sea and inland, etc. (Its maximum load is up to 5 ton) The roatry-base make it flexible on the oilfield floor, and the pin-base assure its safety.

Features:
1. Compact in size and light in weight, portable to move and easy to install;
2. Simple and reliable operation with little noise;
3. Stable in inflammable, explosive, wet, damp and other extremely operating conditions;
4. Low maintenance relieves your anxiety and assures you to use it freely.
5. High starting torque ensures it starting with load and performing hoisting, lowering and stopping actions easily;
6. Especially fit for hauling, lifting and other work in mines, construction engineering sites, platforms of oilfields, etc;
7. The Normal Pull Force can be tailor-made to your requirement;
8. Good after-sale service with high quality.

Items	Parameters	Measurement  Unit
Rated Working Pressure	0.6-0.8	Mpa
Rated Pull Force	50	KN
Rated Cable Speed	12	m/min
Piston Air Motor Model	TMH17	-----
Piston Air Motor Rated Power	17	kW
Piston Air Motor Air Consumption	247	L/S
Drum Diameter	222	mm
Drum Width	335	mm
Drum Wheel Diameter	465	mm
Cable Diameter	15.875	mm
Cable Storage	120	m
Air Inlet Diameter	1 1/4	in
Configuration	1200*920*989	mm
Weight	498	KG
