5t 10m Electric Hoist
Shanghai Yiying Crane Machinery Co., Ltd.- Application：Double Beam Crane, Gantry Crane, Single Grinder Crane, Small Crane, Lifting Equipment
- Type：Electric Hoist
- Sling Type：Chain
- Certification：CE, ISO9001:2000, TUV
- Name：Pdh Electric Hoist
- Hook：Heat Treated
Base Info
- Model NO.：PDH
- Chain：Fec or Made in China
- Brake System：Electromagnetic Brake
- Over Load Limit：Available
- Trolley Type：Available
- Single Speed：Yes
- Double Speed：Available
- Low Headroom：Available
- Chain Bag：Yes
- Transport Package：Wooden Case, Pallets, and So on
- Specification：CE, ISO, TUV
- Trademark：HUGO
- Origin：Shanghai
- HS Code：8425110000
- Production Capacity：50000 PCS,Year
Description
The introduction of 5T 10M Electric Hoist Model PDH-A-0.5 PDH-A-1 PDH-A-2 PDH-A-2.5 PDH-A-3 PDH-A-5 Capacity ( t ) 0.5 1 2 2.5 3 5 Standard lifting height ( m ) 3 Lifting Speed ( m/min ) 7.2 5.8 3.0 5.0 5.0 2.6 Lifting Motor Power (kw) 8 8 14 7 10 5 Volt (V) 220V - 440V Frequency (Hz) 50
Chain Turns 1 1 2 1 1 2 Chain specification (mm) Ø 6.3×19 Ø8×24 Ø8×24 Ø11.2×34 Ø11.2×34 Ø11.2×34 Test load (t) 0.625 1.25 2.5 3.125 3.75 6.25 Net Weight (kw) 41 45 53 108 110 130 Weight added with 1m higher (kg) 1.1 1.4 2.8 2.8 2.8 5.6
