• Model NO.：GKP
• Production Capacity：Depends on Demand

Basic Info.

Model NO. GKP Production Capacity Depends on Demand

Product Description

Supplied with a built-in battery charge indicator.
Complete with levelling indicator and outriggers.
Emergency down and stop buttons.
Semi-eletric order picker are ideal equipment for maintenance work in warehouses,shopping centres,hospitals,schools and other areas,where health and safety are even more important.
More versatile than a mobile tower as its height can be adjusted with the touch of a button.


The semi-electric order picker offers an economical solution for maintenance in warehouse,shoppong centers,when working at height (400kg max lifting capacity)



Model	GKP0.2/2.72	GKP0.2/3.3	GKP0.4/3.5	GKP0.4/4.0	GKP04/4.5
Max.Platform height    mm	2720	3300	3500	4000	4500
Max. machine height   mm	4020	4900	4200	4700	5200
Ground Clearance     mm	30	30	30	30	30
Lift Rated Capacity    kg	200	200	400	400	400
Platform size        mm	600x600	600x640	600x600	600x600	600x600
Lifting Motor       v/kw	12/1.5	12/1.5	1.5	1.5	1.5
Battery           v/Ah	12/120	12/120	12/120	12/200	12/200
Charger            v/A	12/15	12/15	12/15	12/15	12/15
Overall length     mm	1300	1300	1500	1520	1560
Overall width      mm	760	840	900	1000	1100
Overall Height     mm	1760	2040	2250	2500	2750
Self Weight        kg	270	320	420	450	480
