Hot Sell Wire Rope Pulling Winch Hoist Aluminum Winch

Shanghai Yiying Crane Machinery Co., Ltd.
  • Application：Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
  • Type：Lever Hoist
  • Sling Type：Wire Rope
  • Lift Speed：2~8m,min
  • Maximum Lifting Height：20m
  • Chain Falls：Wire Rope

Base Info

  • Model NO.：VIT
  • Certification：CE, ISO9001:2000
  • Condition：New
  • Color：Silver
  • Name：Wire Rope Pulling Winch Hoist
  • Factory：More Than 20 Years Manufactory Experience
  • Loading Port：Shanghai Port Tianjin Port
  • Warranty：2 Years
  • Brand：Hugo
  • Net Weight：23 Kg
  • Applications：Normal Working Environment
  • Painting Color：as Your Order
  • After-Sales Service Provided：Overseas Service Provided
  • Quantity Control：According to EU Standard
  • Transport Package：Packed by Carton, Woodon Case
  • Specification：CE, ISO, TUV, SGS
  • Trademark：HUGO
  • Origin：China-Shanghai
  • HS Code：8425190000
  • Production Capacity：100000PCS,Month

Description

Basic Info.

Model NO. VIT Certification CE, ISO9001:2000 Condition New Color Silver Name Wire Rope Pulling Winch Hoist Factory More Than 20 Years Manufactory Experience Loading Port Shanghai Port Tianjin Port Warranty 2 Years Brand Hugo Net Weight 23 Kg Applications Normal Working Environment Painting Color as Your Order After-Sales Service Provided Overseas Service Provided Quantity Control According to EU Standard Transport Package Packed by Carton, Woodon Case Specification CE, ISO, TUV, SGS Trademark HUGO Origin China-Shanghai HS Code 8425190000 Production Capacity 100000PCS/Month

Product Description

Wire Rope Pulling Winch Hoist Aluminum Winch

The introduction of Wire Rope Pulling Winch Hoist
Certification: ISO, CE, TUV, SGS

Capacity: 3T lever hoist; 6T lever hoist

Standard lifting height: According the inquiry.

1)Capacity from 0.8T to 3.2T

2)High quality aluminium body

3)Overload protection

4)four times tested before packed, it is safty and using.

The specifications of Outdoor Used Wire Rope Pulling VIT Winches

It has such distinct merits as small cubage, light weight, beautiful appearance, small manual force, safety

And reliability. And long opertional life-span, It is especially used in occasion without power source such

As shipbuilding, post office, mines, electric power, and transportation units in heavy goods

Suspending, equipment fixing, mechanism traction, and aerial exercise, it can rapidly unhitch brake

Equipment under unloaed condition. So that the flying hook can remove fleetly, we also can choose and

Add structure without light load limit according to the needs of clients.
Model
HX-800
HX-1600
HX-3200

Rated  capacity        (kg)
800
1600
3200

Rated  forward  hand  power            N
343
441
441

Rated  forward  travel          mm
>   52
>   55
>   28

Rope  diameter      mm
8.3
11
16

load  capacity
5
5
5

Load  capacity
5
5
5

Max  traveling  load  kg
1200
2400
4000

Net  weight        (kg)
6
11
22
