Technical parameters | Unit | SC200/200 Frequency Construction hoists |
Height | m | 300 |
Rated load | kg | 2000/2000 |
Maximum capacity | | 009/009 |
Boom lift wweight | kg | ≤200 |
Lifting speed | m/min | 0-40 0-45 0-55 0-66 |
Electormotor | Model | | YZEJ132M(L)-4 |
Power | kw | 15×2/15×2 11×3/11×3 15×3/15×3 18.5×3/18.5×3 |
Speed-limiter | Model | | SAJ40-1.2A SAJ40-1.4 |
Rated tripping speed | m/s | 1.2/1.4 |
Standard motion speed | m/s | 1.1/1.35 |
Rated automaticload | KN | 40 |
Type | | gradual |
Reducer | Model | | SWC1 TU68T TU66T |
Center distance | mm | 125 |
Speed radio | | 1:12 1:10 |
Bracking distance | m | 0.3-1.2 |
Mast section dimension | mm | 650×650×1508 |
Crane cage inner net dimension | m | 3.0×1.3×2.2 3.2×1.5×2.2 |
Guardrail dimension | m | 5.53×3.42×1.82 5.93×3.62×1.82 |
Hoistway dimensions | m | |
Free end height of the guide rail frame | m | ≤9 |
Gounterweight weight | kg | |
Direct attached frame | Installing interval | m/set | 006-9 |
Distance between two embedded parts | mm | ≈1488 |
Installation dimensions from center of rail frame to building wall | mm | 2800-3200 |
Safe and protection system | Upper and below limited switches,upper and below limit utmost switches,gate limited switch,falling avoiding safe device,cushion device,safe lock of gate,counterweight rope breaking or loose protecting device,safe hook,The safety device against overload,Anti-punching standard section etc. |
