Lifting Machine Xgc130 130 Tons Small Crawler Crane for Sale
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Max. Rated Lifting Capacity:130 T
- Max Load Moment:722 T.M
- Gradeability:30%
- Basic Boom Length:16~76 M
- Jib Length:13-31 M
- Size:11.0*3.0*3.3 M
Base Info
- Model NO.:XGC130
- Engine Power:206 Kw
- Mass of The Vehicle as a Whole:122 T
- Max Mass of Single Unit:37 T
- Warranty:1 Year
- Transport Package:Nude Package
- Specification:ISO, CE, GOST
- Trademark:ORIEMAC
- Origin:Jiangsu, China(Mainland)
- HS Code:84295212
- Production Capacity:800PCS,Month
Description
Basic Info.
Model NO. XGC130 Engine Power 206 Kw Mass of The Vehicle as a Whole 122 T Max Mass of Single Unit 37 T Warranty 1 Year Transport Package Nude Package Specification ISO, CE, GOST Trademark ORIEMAC Origin Jiangsu, China(Mainland) HS Code 84295212 Production Capacity 800PCS/MonthProduct Description
Lifting Machine Xgc130 130 Tons Small Crawler Crane for Sale1. Safety control system:
Two convenient and reliable modes of operation; Working and installation, with real-time level display, stop operation braking away from machine, electrical emergency control, anti-lightning protection, automatically walk switches, CCTV monitoring function, complete safety and supervision system;
2. Excellent operating performance:
Advanced load-sensing, limit load regulation and electrohydraulic proportional micro-speed control make each micro-movement extremely good and operation more stable;
3. Reliable function assurance:
Key components adopt famous international brands; Sufficient safety margin for structural and mechanical design; Control system can operate stably in harsh environments such as cold, high temperature, altitude and sandy conditions;
4. Convenient maintenance technology:
It takes approximately no more than 10min/person to adjust; No more than 30min/per son for dai ly maintenance; No more than 2h/person to repair. GPS remote monitoring system is optional for maintenance and management;
5. Powerful lifting capacity:
The maximum lifting capacity of boom is 50t× 3.7m=185t· M, and the max. Length of main boom is 52m;
6. Flexible configuration combination:
Free hook is optional;
7. Large-chassis design:
Track frame which can be broadened, ensuring excellent machine and job stability within the range of 360 ° Rotation;
8. Optimized transportation programs:
With the function of crawler frame telescopic function, the max. Transportation width of the whole machine is 3.36m;
9. Two counterweight configurations:
Improve the lifting capacity of medium and long boom.
Items | Unit | Data |
---|---|---|
Basic boom | T | 135 |
Fixed jib | T | 20 |
Max. load moment | t/m | 722 |
Boom length | M | 16-76 |
Boom working condition | . | 30-80 |
Fixed jib working condition | . | 30-80 |
Fixed jib length | M | 13-31 |
Winch mechanism max single line speed(no load, at 5th layer) | m/min | 120 |
Boom elevating mechanism max. single line speed(no load, at 3rd layer) | m/min | 2×45 |
Max slewing speed | r/min | 1.5 |
Max traveling speed | Km/h | 1.3 |
Grade ability | % | 30 |
Average ground pressure | Mpa | 0.089 |
Engine power | Kw | 206 |
Mass of the vehicle as a whole( including main hook block and 16m boom) | T | 122 |
Max mass of single unit in travel configuration | T | 37 |
Max dimension of single unit in travel configuration(L×W×H) | m | 11.0×3.0×3.3 |
