Beam Clamp with Shackle and Ring (BC-WB)

Hangzhou Nuohao Industry Co., Ltd.
  • Capacity：0.5ton to 10ton
  • Condition：New
  • Certificateion：CE, ISO9000:2001
  • Type：Beam Clamp
  • Proof Load：12.5kn to 125kn
  • Beam Width：75-230mm; 80-320mm

Base Info

  • Model NO.：BC-WB
  • Transport Package：Carton Packing or Wooden Pallet Packing
  • Specification：CE GS and TUV
  • Trademark：LTN, NorHo Or OEM
  • Origin：Hangzhou China
  • HS Code：8428909090
  • Production Capacity：5000sets,Month

Description

  1T 2T 3T 5T 10T
  1 2 3 5 10
  75-230 75-230 80-320 80-320 90-320
  4.2 5.1 10.4 12.2 18.8
A 240 240 330 330 330
B min 192 192 243 243 259
B max 367 367 491 491 501
C 94 102 132 132 180
D 4 6 8 10 12
 E  218 218 258 258 293
F min 103 103 157 157 175
F max 155 155 223 223 235
G 20 20 47 47 56
H 30 30 45 45 64
