• Model NO.：LRL3-4
• Feature：Explosion-Proof
• Certification：CE, ISO 9001
• Platform：Antiskid
• Installation：Platform in Pit
• Pit Depth：160mm
• Color：Red, Green, Blue or as Your Requirements
• Guardrail Height：1100mm
• Stops：2
• Chain：16A
• Lift Speed：3-6m,Min
• Platform Size：1500*2200mm
• Loading & Unloading：From 2200mm Side
• Transport Package：Nude Packing or According Your Requirement
• Specification：CE, ISO
• Trademark：MORN
• Origin：China
• HS Code：8428909090
• Production Capacity：30 Units,Month

ModelLRL1-5.2LRL2-5LRL3-10LRL10-7LRL5-10Capacity1000kg2000kg3000kg10000kg5000kgTravel height5.2m5.8m10m7m10mPlatform size2.5*1.5m1.6*1.8m2.3*1.9m3.4m7.37*2.25mLoading direction2.5m1.6m1.9m3.4m7.37mLift driveHydraulicHydraulicHydraulicHydraulicHydraulicShaft size3.15*1.65m2.25*1.95m2.9*1.9m4.1*4.5m7.47*2.95mPower3kw4kw5.5kw11kw7.5kw



After-sale Services

1. User-friendly English manual for machine using and maintenance.
2. One year warranty for whole machine without man-made fault;
  10 year warranty on main structures.
3. Free parts available if there is any nonhuman factors problem during warranty time.
4. 7*24-hours technical support by email, telephone or other communication online; engineers are available to go offshore if necessary.
