• Model NO.：SC200,200
• Transport Package：Container
• Specification：2t
• Trademark：FYG
• Origin：Shandong, China
• HS Code：8428909090
• Production Capacity：10 Sets Per Month

Technical parameters

 Unit

 SC200/200 Frequency Construction hoists Height m

 300

 Rated load kg2000/2000  Maximum capacity  009/009  Boom lift wweight kg≤200  Lifting speed m/min 0-40 0-45 0-55 0-66 Electormotor  Model  YZEJ132M(L)-4

 Power

 kw 15×2/15×2 11×3/11×3 15×3/15×3 18.5×3/18.5×3 Speed-limiter   Model   SAJ40-1.2A   SAJ40-1.4 Rated tripping speed m/s 1.2/1.4 Standard motion speed  m/s 1.1/1.35 Rated automaticload KN

 40

 Type  gradual Reducer Model  SWC1  TU68T  TU66T Center distancemm 125 Speed radio  1:12  1:10 Bracking distancem 0.3-1.2 Mast section dimensionmm 650×650×1508 Crane cage inner net dimensionm 3.0×1.3×2.2  3.2×1.5×2.2 Guardrail dimensionm 5.53×3.42×1.82 5.93×3.62×1.82 Hoistway dimensionsm  Free end height of the guide rail framem ≤9 Gounterweight weightkg  Direct attached frame Installing intervalm/set 006-9 Distance between two embedded partsmm ≈1488 Installation dimensions from center of rail frame to building wallmm 2800-3200 Safe and protection system Upper and below limited switches,upper and below limit utmost switches,gate limited switch,falling avoiding safe device,cushion device,safe lock of gate,counterweight rope breaking or loose protecting device,safe hook,The safety device against overload,Anti-punching standard section  etc.
