• Driven Type：Hydraulic
• Running Mode：Stationary
• Feature：Explosion-Proof, Insulating
• Certification：CE, ISO 9001
• Rated Loading Capacity：200kg
• Max. Lifting Height：Customized
• Table Size：1430*900mm
• Control System：Both on The Platform and Ground
• Material：Aluminum Alloy
• Remote Control：Yes
• Emergency Stop：Manual Emergency Stop Valve
• Platform Safety：Underpan Sensor(Optional)
• Installation：on The Ground
• Transport Package：Plywood Case
• Specification：1430x1500x4050mm
• Trademark：MORN
• Origin：Shandong China
• HS Code：8428909090
• Production Capacity：200 Units Per Month

Name
No.
Lift capacity (kg)
Materials
Wheel-chair vertical lift
WL0.25-N
250Aluminum Alloy
Platform size
1430mm(L)* 1000mm(W)
Dimension
1430mm(L)*1000mm(W)* [Travel height +1600mm(H)]
Max Platform Height
N(mm)
Min Platform height
80mm
Configuration
Open through or front and side entrances
Speed
100mm/s
Load capacity
250KG
Control voltage
24V/DC
Power Output
0.75kw-2.2kw
Power Input
220V/50HZ (or customized for local power supply)
Drive System
Hydraulic
Control Mode
Inching Switch or Automatic
Drive Control
Self-resetting system
Overload
Protection Over current relay
Material of Platform
Spraying plasticGuard panel & drive cabinet (framework)Spraying plastic
Automatical ramp
yes
Column switch
Two column switch, one is on the ground floor, one on the first floor
Operation Panel
Polished Stainless steel(up down and Emergency drop valve)
Safety Wane Working Range
75°
Working Condition
Both indoors and outdoors
Working temperature
From -10°~60°C
Installation

Non-pit installation, directly fixed to concrete floor (the concrete
floor below the platform shall not be lower than the ground)
Control Device

Calling box (installed on the wall nearby) and remote
controller(Extra optional)
Emergency Stop

The lifting and lowering process can be stopped immediately
by pressing the emergency button.
3. Company Information

MORN has devoted itself to the research and development, design and manufacture, salesand service of home lift, scissor lift, cargo lift and other hydraulic equipment. As a more than 8 years export experience supplier of hydraulic equipments supplier, Sinicmech machinery has
more than 20000 square meters producing shop and assembly shop.

That we have many advanced production equipment for cutting steel structure, machine
parts, including scissor structure, platform, hinge pin, beams, articulated boom and other
small parts. which made the precise scissor lift structure and boom lift, beams, and even
the small needed parts, this is a great improve for our products quality and user's safety.

4. After-sale service

A. We offer 12 month warranty apart from artificial faults, during warranty time, we will bear the cost of parts.
B. If it is necessary for you, our engineer are available to service.
C. We offer 24 hours service for technical support and any assistance.
