• Model NO.：HLD-QDB-2
• Condition：New
• Max Lifting Tons：5t
• Air Source：0.8MPa
• Max Lifting Height：1720mm
• Using Way：Pit Use
• Transport Package：Export Plywood Case
• Specification：ISO9001
• Trademark：Haolida
• Origin：Shandong, China
• HS Code：8425429000
• Production Capacity：200sets Per Year

Basic Info.

Model NO. HLD-QDB-2 Condition New Max Lifting Tons 5t Air Source 0.8MPa Max Lifting Height 1720mm Using Way Pit Use Transport Package Export Plywood Case Specification ISO9001 Trademark Haolida Origin Shandong, China HS Code 8425429000 Production Capacity 200sets Per Year

Product Description

  HLD-QDB-2 model automobile gearbox pit dismounting machine
1.Fucntion introduction
Gearbox pit dismounting machine is pit floor type gearbox trailer,it adopts pneumatic hydraulic pump,takes compressed air as power,air and hydraulic convert,no need electric ,it is safe to operate.
Its lift platform is equiped with hydraulic device,can adjust multi-angle of the platform,it is convenient to lift and disassemble various kinds of gearboxes and differentials of buses or heavy load vehicles.
It is with features of compact structure,long lifting stroke,convenient using.
It can be used on the groung or in the pit(can make according to the pit size;electric hdyraulic power is selectable).
2. Technical parameter
a. air source: 0.8Mpa
b. Maximum lifting power:50KN
c. Maximum lifting height: 1720mm
d. Minimum lifting height:790mm
e. overall dimension(L*W*H):1100*720*790mm
f. total weight: 140kgs
