• Model NO.：HSY electric chain hoist
• Lift Speed：2~8m,min
• Maximum Lifting Height：>20m
• Chain Falls：2
• Certification：CE
• Condition：Used
• Color：Yellow
• Hook：Forged
• Voltage：220-440V
• Phase：3 Phase
• Standard Lifting：3m
• Chain Hoist：Yes
• Double Speed：Can Supply
• Delivery Time：Within 5 Days After Payment
• Transport Package：Wooden Case
• Specification：70*37*43
• Trademark：hugo
• Origin：China
• HS Code：84251100
• Production Capacity：5000
• Package size per unit product：61.00cm * 49.00cm * 72.00cm
• Gross weight per unit product：97.000kg

Basic Info.

Model NO. HSY electric chain hoist Lift Speed 2~8m/min Maximum Lifting Height >20m Chain Falls 2 Certification CE Condition Used Color Yellow Hook Forged Voltage 220-440V Phase 3 Phase Standard Lifting 3m Chain Hoist Yes Double Speed Can Supply Delivery Time Within 5 Days After Payment Transport Package Wooden Case Specification 70*37*43 Trademark hugo Origin China HS Code 84251100 Production Capacity 5000

Packaging & Delivery

Package size per unit product 61.00cm * 49.00cm * 72.00cm Gross weight per unit product 97.000kg

Product Description

380v 3 phase electric chain hoist with hand trolley for lifting winch


1. Hooks
Instructions of Latest Hot Selling!! Custom Design low clearance electric chain hoist with good prices
Drop forged steel suspension & load hooks are heat treated and fracture resistant. In case of dangerous overloading or abuse, the hook does not fracture but will slowly yield.
2. Power
Operating voltage 220-440V, 50/60Hz, 1-3 phase.
Low voltage control 36V is standard.
3. Motor
High efficient energy-saving motor, asbestos free brake system. 2-speed motor available.
4. Chain
Alloy steel chain super strong surface hardened for optimum strength and wear resistance.
5. Chain Bucket
Solid chain bucket as standard part for safer operation
6. Limit Switch
Limit switch devices fitted at both top & bottom ends, switch off power automatically to prevent load chain from running out.
7. Phase Error Relay
Phase error relay, a specially designed current-post, prevents motor from running at incorrect wire connection.
8. Pushbutton Swith
Pushbutton swith is rain-proof plastic for severe impact and corrosive atmosphere resistance and mechanically interlocked.
9. Safety Latches
Top and bottom hooks are fitted with safety latches as standard.
10. Light Wight
Light weight, compact and solid body case.
11. Push Button Control
Fits operator's hand operation. Impact and chemical atmosphere resistant.


  Before delivery HUGO brand electric hoist is tested by the no-load and load for many times.
