• Driven Type：DC
• Running Mode：Moving
• Feature：Explosion-Proof, Insulating
• Certification：GS, CE, RoHS, ISO 9001
• Color：Yellow, Red, Green, Customized
• Capacity：420kg
• Lifting Height：2400mm
• Machine Length：2840mm
• Machine Width：1180mm
• Turning Radius：2150mm
• Grade Ability：3%
• Wheel Size：Dia 250X80mm
• Brake Type：Electromagnetism Brake
• Drive Motor：1.2kw
• Lifting Motor：2.2kw
• Noise：<70 Dba
• Battery：24V,210A
• Rotation Angle：135 Degree
• Machine Weight：1000kg
• Transport Package：Timer Box
• Specification：5CBM
• Trademark：PLK LIFT
• Origin：China
• HS Code：8428909090
• Production Capacity：47000

Basic Info.

Driven Type DC Running Mode Moving Feature Explosion-Proof, Insulating Certification GS, CE, RoHS, ISO 9001 Color Yellow, Red, Green, Customized Capacity 420kg Lifting Height 2400mm Machine Length 2840mm Machine Width 1180mm Turning Radius 2150mm Grade Ability 3% Wheel Size Dia 250X80mm Brake Type Electromagnetism Brake Drive Motor 1.2kw Lifting Motor 2.2kw Noise <70 Dba Battery 24V/210A Rotation Angle 135 Degree Machine Weight 1000kg Transport Package Timer Box Specification 5CBM Trademark PLK LIFT Origin China HS Code 8428909090 Production Capacity 47000

Product Description

650kg Full Electric Mobile Oil Drum Lifter
  Introduction:
1.This equipment is suitable for handling, lifting, loading and unloading of 55 gallon steel drums. The equipment adopts a dedicated walking control system for imported electric vehicles. Stable walking, lightweight and flexible, it can be operated by one person.
2.Man-machine multi-function control handle, walking stepless speed governor, high power reversing switch, integrated hydraulic pump station, high power walking drive wheel.
Loaded pedals reduce operator fatigue
3.Electro-hydraulic holding clamp, electro-hydraulic flip

Model	ST-650A	ST-650A-1  (With electronic scale)	ST-650B
Load Capacity	650kg	650kg	650kg
Lifting Height	2400mm	2400mm	2400mm
Overall Length	1960mm	1960mm	1450mm
Overall Width	1006mm	1006mm	865mm
Overall Height	1860mm	1860mm	1860mm
Tilting Range	Electric rotating 180°	Electric rotating 180°	/
Driving Motor	1.2kw	1.2kw	1.2kw
Lifting Motor	2.2kw	2.2kw	2.2kw
Battery	24V/30A	24V/30A	24V/30A
Charger	24V/120Ah/	24V/120Ah/	24V/120Ah/
Driving Wheel	φ250*80mm	φ250*80mm	φ250*80mm
Front Wheel	Φ80*55mm	Φ80*55mm	Φ80*55mm
Tire	Polyurethane	Polyurethane	Polyurethane
Noise Level	<70db(A)	<70db(A)	<70db(A)
Net Weight	518	525	470
Gross Weight	558	565	510
Packing Size	196*100*201cm	196*100*201cm	145*87*201cm
Function	Without scale	With electronic weighing function	Without scale

Photos Display:

Our Service:1.We can design the customerized aerial scissor man lift as per your requirement.
2.The most suitable model will be recommended to you once we know about your requirement.
3.Shipment can be arranged from our port to your destination port.
4.Opetion video can be sent to you if needed.
5.Maintenance video will be given once the electric scissor lift table break down to help you repair.
6.Parts of aerial scissor man lift can be sent to you by express within 7 days if needed.

Frequently Asked Questions:
1.How can customer  buy parts once it break down?
The aerial scissor man lift adopt most of the common parts of hardware.You can buy the parts in your local hardware market.
2.How can customer repair the aerial scissor man lift.
One of the great advantage of the equipment is with very very low failure rate.Even it breaks down,we can guide to repair it by video and repair instruction.
3.How long is the quality guarantee?
One year quality guarantee.If it breaks down within one year,we can send the parts free of charge to you.

Factory Show:
