600kg Fully Powered Mobile Glass Vacuum Lifter
Jinan PLK Machinery Co., Ltd.- After-sales Service：Free Spare Parts Replacement
- Warranty：1 Year
- Cup Quantity：6
- Color：Green, Red, Blue, Yellow, Customized
- Load Capacity：200kg, 300kg, 400kg, 500kg, 600kg, 800kg
- Working Height：3.5m, 4m, Can Be Cusomized
Base Info
- Model NO.：GL
- Panel Size：Customize, We Design to Fit The Panel Size
- Battery Power：24V, 120ah
- Drive Motor：24V 900W
- Hydraulic Power：24V 2000W 5L
- Cap Diameter：250mm or 300mm
- Usage：Various Plates Lifting, Moving and Intalling
- Features 1：Dual Pneumatic Control System
- Features 2：Heavy Duty Cylinders with Drainage System
- Machine Weight：800kg - 1000kg
- Lift Mechanism：Telescoping Lift
- Moves：Self-Propelled
- Transport Package：Timer Box
- Specification：6CBM
- Trademark：PLK LIFT
- Origin：China
- HS Code：8428909090
- Production Capacity：50000 Set Per Year
Description
N.W/G.W
780/820kg
800/850kg
1200/1250kg
1600/1700kg
Advantages
1. Integrated control system secures quick and automatic positioning vertically and horizontally by a single push on a button.
2. DC24V reliable actuators for lifting, extension and tipping. efficient and precise. Self propelling, various circuit vacuum suction.
3. Attractive price, staff saving, strong improvement of working environment.
4. Vacuum lifter are dealt with shot blasting and stoving varnish, high anti-corrosion function.
5. High quality pump station make the vacuum lifter lifts and falls very stably.
6. Heavy duty cylinders with drainage system and check valve to stop the scissor lift table lowering in the case of hose burst.
7. Pressure relief valve prevent overload operation; Flow control valve make descent speed adjustable.
8. Brief structure make it much easier to operate and maintain.
9. Up to American standard ANSI/ASME and Europe standard EN1570.
