2t Hand Stacker with Certificate
Niuli Machinery Manufacture Co., Ltd.- After-sales Service：Online Service
- Warranty：One Year
- Type：Manual Stacker
- Customized：Cost-Effectiv Handling
- Transport Package：Cast Cage
- Trademark：Niuli or OEM
Base Info
- Model NO.：CTY-D2.0
- Origin：Guangdong China
- Production Capacity：Depends on Demands
Description
Basic Info.
Model NO. CTY-D2.0 Origin Guangdong China Production Capacity Depends on DemandsProduct Description
Hand stacker is hand push&hand lift stacker which provides cost-effective handling for both vehicle loading and production areas.Easy maintenance and low running costs.Adjustable forks to coordinate with different requirements.
Ergonomic rubber handle ensures a comfortable easy operation.
Effortless and quick lifting for using foott pedal without loads.
| Model | CTY.D1.0 | CTY.D2.0 |
| Rated lifting Capacity(kg) | 1000 | 2000 |
| Max lifting height(mm) | 1600 | 1600 |
| Lowed height of forks(mm) | 85 | 85 |
| Fork lengtht(mm) | 900 | 900 |
| Adjustable width of forks | 200-580 | 240-780 |
| Lifting speed(mm/stroke) | 20 | 14 |
| Lowing speed(mm/stroke0 | controllable | controllable |
| Operation power of crank(kg) | 24 | 32 |
| Outer width of front legs(mm) | 790 | 830 |
| Min.refuel volume for fuel tank(L) | 3.0 | 2.0 |
| Front wheel size | 80x70 | 80x93 |
| Rear wheel size | 180x50 | 180x50 |
| Overall size | 2050x780x1650 | 2030x830x1500 |
| Self weight | 160 | 260 |
