• Model NO.：XGC85
• Engine Power：200kw
• Engine Model：Sc9dk270g3,Qsc8.3
• Max. Mass of Single Unit in Transport St：41.2 T
• Warranty：1 Year
• Transport Package：Nude Package
• Specification：ISO, CE, GOST
• Trademark：ORIEMAC
• Origin：Jiangsu, China(Mainland)
• HS Code：84295212
• Production Capacity：800PCS,Month

Basic Info.

Model NO. XGC85 Engine Power 200kw Engine Model Sc9dk270g3/Qsc8.3 Max. Mass of Single Unit in Transport St 41.2 T Warranty 1 Year Transport Package Nude Package Specification ISO, CE, GOST Trademark ORIEMAC Origin Jiangsu, China(Mainland) HS Code 84295212 Production Capacity 800PCS/Month

Product Description

Hoist Construction Equipment 85 Ton Crawler Crane XGC85 for Sale

Overview

XGC85  crawler crane

XGC85 is a new generation crawler crane which is successfully developed by after QUY80 series. Inheriting the advantages from the old generation product, XGC85 crawler crane pays more attention to the improvement of lifting performance, assembly/disassembly and transport economy, maintenance convenience and operation comfort. The system is mature and reliable with complete safety devices. Fitted with multiple advanced technologies, such as gantry self-erecting function, basic machine integration transport and etc, the crane's performance is superior to that with other domestic brands in various aspects.
An overall research on market application was carried out during the initial development period of XGC85 crawler crane, main and aux. hook one-key switch function is specially designed, greatly improve the lifting operation efficiency.

Features:

1. Safety control system:
Two convenient and reliable modes of operation; Working and installation, with real-time level display, stop operation braking away from machine, electrical emergency control, anti-lightning protection, automatically walk switches, CCTV monitoring function, complete safety and supervision system;

2. Excellent operating performance:
Advanced load-sensing, limit load regulation and electrohydraulic proportional micro-speed control make each micro-movement extremely good and operation more stable;

3. Reliable function assurance:
Key components adopt famous international brands; Sufficient safety margin for structural and mechanical design; Control system can operate stably in harsh environments such as cold, high temperature, altitude and sandy conditions;

4. Convenient maintenance technology:
It takes approximately no more than 10min/person to adjust; No more than 30min/per son for dai ly maintenance; No more than 2h/person to repair. GPS remote monitoring system is optional for maintenance and management;

5. Powerful lifting capacity:
The maximum lifting capacity of boom is 50t× 3.7m=185t· M, and the max. Length of main boom is 52m;

6. Flexible configuration combination:
Free hook is optional;

7. Large-chassis design:
Track frame which can be broadened, ensuring excellent machine and job stability within the range of 360 ° Rotation;

8. Optimized transportation programs:
With the function of crawler frame telescopic function, the max. Transportation width of the whole machine is 3.36m;

9. Two counterweight configurations:
Improve the lifting capacity of medium and long boom.


Item	Unit	Parameter value
Parameter Item	-	XGC85
Operation performance parameter		*
Max. rated lifting capacity for boom	(t)	85
Max. rated lifting capacity for fixed jib	(t)	12
Max. rated lifting capacity for luffing jib	(t)	-
Max. load moment	(t.m)	341
Max. rated lifting capacity for tower jib	(t)	-
Max. rated lifting capacity for boom single top	(t)	8
Max. rated lifting capacity for special jib	(t)	-
Dimension parameter		*
Boom length	(m)	13~58
Boom luffing angle	(°)	-3~80
Fixed jib length	(m)	7~19
Tower jib length	(m)	-
Max. dimension of single unit in transport state(L×W×H)	(m)	13.05×3.4×3.3
Fixed jib offset angle	(°)	10,30
Special jib length	(m)	-
Speed parameter		*
Max. single line speed for hoist mechanism	(m/min)	120
Max. single line speed for boom luffing mechanism	(m/min)	70
Max. single line speed for jib luffing mechanism	(m/min)	-
Max. slewing speed	(r/min)	2
Max. travel speed	(km/h)	0.9
Grade ability	(%)	30
Mean ground pressure	(MPa)	0.087
Max. single line speed for tower jib luffing mechanism	(m/min)	-
Max. single line speed for superlift luffing	(m/min)	-
Engine		*
Model	-	SC9DK270G3/QSC8.3
Engine power	(kW)	200/183
Emission	-	National III/ EU III
Mass parameter		*
Overall crane mass	(t)	71.5(main hook, 1
