New Brand Full Electric Stacker
Niuli Machinery Manufacture Co., Ltd.- Lifting Height：Customized
- Structure：Hydraulic Jack
- Power Source：Electric
- Transport Package：Wooden Case
- Specification：NIULI
- Trademark：NIULI
Base Info
- Model NO.：SPN15
- Origin：Heshan City, Guangdong Province, China.
- HS Code：8427900000
- Production Capacity：20000PCS
Description
Basic Info.
Model NO. SPN15 Origin Heshan City, Guangdong Province, China. HS Code 8427900000 Production Capacity 20000PCSProduct Description
The Full Electric Stacker with different loading capacities and various lifting heights is built for stacking in intensive applications in stores and factories, applications that require durable high capacity trucks that are also capable of horizontal transport purposes.1. Capacity: 1000kg, 1300kg, 1500kg. 2000KG
2. MAx Lifting Height: 1600mm, 2000mm, 2500mm, 3000mm, 3300mm. 3500-5500MM.
3. Min Forks Height: 85mm.
4. Fork Of Length: 1020mm.
5. Overall Width: 820mm.
6. Charhing Voltage: AC220V.
7. Battery Charger: 24/30/40 (V/A)
| Model | CTQ10/16,15/16,20/16 | CTQ10/20,15/20,20/20 |
| Capacity(kg) | 1000/1500/2000 | 1000/1500/2000 |
| Load center(Qmm) | 500 | 500 |
| Front wheel size(mm) | φ80x60 | φ80x60 |
| Rear wheel size(mm) | φ130x55 | φ130x55 |
| Traction wheel(mm) | φ250x80 | φ250x80 |
| Fork Dimensions(L3mm) | 1150x160x60 | 1150x160x60 |
| Max.lifting height(H2mm) | 1600 | 2000 |
| Extended height(H3mm) | 2080 | 2500 |
| Closed height H3(H1mm) | 2080 | 1580 |
| Fork clearance from ground(H5mm) | 80-90 | 80-90 |
| Total length(L1L2mm) | 2070/2360 | 2070/2360 |
| Total width(Bmm) | 815 | 815 |
| Max.fork width(B1mm) | 680 | 680 |
| Turning radius (open pedal)(R1mm) | 1950 | 1950 |
| Self Weight(without battery)(kg) | 710740750 | 730760770 |
| Battery charger | AC220V/50Hz DC24V/40A | AC220V/50Hz DC24V/40A |
