Ship Launching Winch Pulling Boat up and Free Down

Pingyang Construction Hoisting Machinery Co.
  • Type：Electric Winch
  • Driven Type：AC
  • Speed：Slow
  • Carrying Capacity：Special Weight Level
  • Tonnage：40ton
  • Running Mode：Stationary

Base Info

  • Model NO.：JM30
  • Feature：Drum Can Free
  • Certification：ISO 9001
  • Standard：Nonstandard
  • Rope Speed：10m,Min
  • Line Pull Capacity：50ton
  • Rope Capacity：800m
  • Brake：Double Brake
  • Transport Package：Naked
  • Specification：21000kg dead weight
  • Trademark：CH
  • Origin：Wenzhou, China
  • HS Code：8425319000
  • Production Capacity：1 Set Per Month

Description


Model

JM20

JM30

JM40

Rated load (kg)

20000

30000

40000

Wire rope average speed (m/min)

10

10

10

Wire rope( mm):

39

42

48

Reduction box

Type

JZQ750

JZQ850

JZQ850

Transmission ratio

31.5

40.17

23.34

Drum (mm)

Diameter(mm)

750

960

1100

Length

1830

1960

1460

Capacity(m)

600

650

800

Motor

voltage

380V/50H

380V/50H

380V/50H

Power(kW)

45

75

90

Rotate speed(r/min)

965

969

720

Electric-hydraulic Brake Type

YWZ-400

YWZ-400

YWZ-500

Dimension (mm)

4000x3000x1700

4500 x2300 x220 0

5500 x2800 x2200

Weight(kg)

8500

11000

19000
