• Model NO.：LH
• Motor：Nanjing or Nanjing Special Motor
• GB/T 24001-2004 Idt ISO140012004：Pass
• GB/T 19001-2000 Idt ISO 9001: 2000：Pass
• Transport Package：Exporting Standard
• Specification：Chinese Standard
• Trademark：Kuangyuan
• Origin：Xinxiang, Henan Province, China
• HS Code：84251100
• Production Capacity：20000sets,Year

ModelCD1 MD1CapacityTons0.250.512351016Hoisting heightM3, 6, 96, 9, 126, 9, 12, 18, 24, 309, 12, 18, 24, 30Hoisting speedM/MIN8(0.8/8)8(0.8/8)8(0.8/8)7(0.7/7)3.5 (0.35/3.5)Travel speedM/MIN2020/3020/3020/3020/3020/3020/3018Wirerope Dia. (mm)3.64.87.41113151517.5Spec.6x396x37+FC6x37+FC6x37+FC6x37+FCHoisting motorTypeTypeZD112-4ZD121-4ZD122-4ZD131-4ZD132-4ZD141-4ZD151-4ZD151-4ZDS1 0.2/0.8ZDS1 0.2/1.5ZDS1 0.4/3.0ZDS1 0.4/4.5ZDS1 0.8/7.5ZDS1 1.5/13ZDS1 1.5/13PowerPower(kW)0.40.8(0.2/0.8)1.5(0.2/1.5)3.0(0.4/3.0)4.5(0.4/4.5)7.5(0.8/7.5)13(1.5/13)13(1.5/13)Rotation speedRotation speed(r/min)13801380138013801380140014001400Current(A)1.252.2(0.72/2.4)4.3(0.72/4.3)7.6(1.25/7.6)11(2.4/11)18(2.4/18)30(5.2/30)30(5.2/30)Travel motorTypeTypeZDY110-4ZDY111-4ZDY111-4ZDY112-4ZDY112-4ZDY121-4ZDY121-4ZDY121-4PowerPower(kW)0.060.20.20.40.40.80.8x20.8x2Rotation speedRotation speed(r/min)14001380138013801380138013801380CurrentCurrent(A)0.30.720.721.251.252.42.42.4Power                                               AC 380V, 50HZ, 3P(As your demand)
