Electric Hydraulic Vacuum Glass Panles Lifter
Jinan PLK Machinery Co., Ltd.- After-sales Service：Free Spare Parts Replacement
- Warranty：1 Year
- Cup Quantity：6
- Color：Green, Red, Blue, Yellow, Customized
- Load Capacity：100kg to 800kg
- Lifting Height：1..5m to 3.5m, Customized as Need
Base Info
- Quantity of Suction Caps：4 PCS, 6 PCS, 8 PCS, Customized
- Suction Cap Diameter：300mm
- Hydraulic Motor：24V,2000W
- Drive Motor：24V,900W
- Suction Plate Size：Customized as Need
- Battery：2X12V,70ah to 2X12V,160ah, for Various Modes
- Operation Mode：Walking Type or Self Propelled Type
- Charger：24V,20A
- Working Principle：Hydraulic Lifting and Vacuum Sucking
- Feature：Explosion-Proof, Insulating
- Certification：GS, CE, RoHS, ISO 9001
- Transport Package：Timer Box
- Specification：6CBM
- Trademark：PLK LIFT
- Origin：China
- HS Code：8428909090
- Production Capacity：50000 Set Per Year
Description
N.W/G.W
780/820kg
800/850kg
1200/1250kg
1200/1250kg
1600/1700kg
| Model | GL-HD-8015(6) | GL-HD-8025(8) | GL-HD-6015(4x30) | GL-HD-4015(4x30) |
| Max. Load Capacity | 800kgs | 800kgs | 600kgs | 400kgs |
| Safe Load Capacity | 400kgs | 400kgs | 300kgs | 200kgs |
| Lifting Height | 1500mm | 2500mm | 1500mm | 1500mm |
| QTY of Caps (customized) | 6pcs | 8pcs | 4pcs | 4pcs |
| Cap Diameter | Ø300mm | Ø300mm | Ø300mm | Ø300mm |
| Plate Size (or customized) | 3660x2440mm | 3660x2440mm | 2440x1830mm | 1220x1830mm |
| Drive Motor | 24V/900W | 24V/900W | 24V/700W | 24V/500W |
| Hydraulic Motor | 24V/2000W | 24V/2000W | 24V/2000W | 24V/2000W |
| Battery | 2x12V/160Ah | 2x12V/160Ah | 2x12V/100Ah | 2x12V/70Ah |
| Charger | 24V/20A | 24V/20A | 24V/15A | 24V/10A |
Advantages
1. Integrated control system secures quick and automatic positioning vertically and horizontally by a single push on a button.
2. DC24V reliable actuators for lifting, extension and tipping. efficient and precise. Self propelling, various circuit vacuum suction.
3. Attractive price, staff saving, strong improvement of working environment.
4. Vacuum lifter are dealt with shot blasting and stoving varnish, high anti-corrosion function.
5. High quality pump station make the vacuum lifter lifts and falls very stably.
6. Heavy duty cylinders with drainage system and check valve to stop the scissor lift table lowering in the case of hose burst.
7. Pressure relief valve prevent overload operation; Flow control valve make descent speed adjustable.
8. Brief structure make it much easier to operate and maintain.
