Wall Mounted Rack & Pinion Jack - Mjw Series
Nu-Lift Equipment Co., Ltd.- Type：Mechanical Jack
- Structure：Screw Jack
- Power Source：Lever
- Transport Package：1PC,Carton
- Specification：CE
- Trademark：NU-LIFT
Base Info
- Model NO.：MJW1.5, MJW3, MJW5, MJW10
- Origin：Jiangsu, China(Mainland)
- HS Code：8425421000
- Production Capacity：5000PCS,Month
Description
|
Model |
MJW1.5 |
MJW3 |
MJW5 |
MJW10 |
|
|
Rated Capacity |
t |
1.5 |
3 |
5 |
10 |
|
Overall Dimension |
mm |
151×156×1090 |
164×212×975 |
188×219×1170 |
220×274×1240 |
|
Crank Force |
kg |
≤28 |
≤28 |
≤28 |
≤40 |
|
Rack Length |
mm |
1090 |
975 |
1170 |
1240 |
|
Lift H |
mm |
≥800 |
≥565 |
≥700 |
≥700 |
|
Net Weight |
kg |
10.5 |
18.5 |
28.7 |
40 |
|
Packing Dimensions |
cm |
17×17.5×112.5 |
18.5×23×101 |
20.5×23.5×120.5 |
24×29.5×127.5 |
|
A |
mm |
100 |
120 |
120 |
140 |
|
B |
mm |
21 |
21 |
21 |
30 |
|
C |
mm |
20 |
25 |
25 |
30 |
|
D |
mm |
20 |
25 |
45 |
30 |
|
E |
mm |
12.5 |
14.5 |
17 |
21 |
|
F |
mm |
310 |
395 |
410 |
480 |
|
G |
mm |
260 |
305 |
320 |
410 |
|
I |
mm |
151 |
212 |
219 |
274 |
|
J |
mm |
156 |
164 |
188 |
220 |
|
K |
mm |
250 |
250 |
250 |
300 |
