• Model NO.：350
• Total Mass (with 350t Hook Block,24m Hea：325t
• Max. Weight of Single Part(Main Machine)：55t
• Dimension of Single Part(Main Machine) I：10.36X3.4X.0m
• Transport Package：in Nude Package
• Specification：CE
• Origin：China
• HS Code：84289090
• Production Capacity：500units,Month

Basic Info.

Model NO. 350 Total Mass (with 350t Hook Block,24m Hea 325t Max. Weight of Single Part(Main Machine) 55t Dimension of Single Part(Main Machine) I 10.36X3.4X.0m Transport Package in Nude Package Specification CE Origin China HS Code 84289090 Production Capacity 500units/Month

Product Description

Item Unit Data
Max. Lifting capacity t 350

Standard working condition
Heavy boom length m 24-84/350
Light boom length m 42-102/190
Fixed Jib length m 12-36/80
Tower attachment length m 24-72/165

Standard superlift working condition
Heavy boom length m 36-84/350
Light boom length m 78-120/190
Fixed Jib length m 12-36/80
Tower attachment length m 24-72/190
Max. Single line hoisting speed( with no load, at 6th layer) m/min 130
Max. Single line speed for boom elevating system(with no load, at 6th layer) m/min 44× 2
Max. Single line speed for tower attachment elevating system(with no load, at 6th layer) m/min 110
Max. Single line speed for sideways superlift elevating system (with no load, at 6th layer ) m/min 110
Swing speed r/min 1.0
Propel speed km/h 0.95
Mean ground pressure MPa 0.13
Engine output kW 310
Total mass (with 350t hook block, 24m heavy boom) t 325
Max. Weight of single part(main machine) in transport state t 55
Dimension of single part(main machine) in transport state(L× W× H) m 10.36× 3.4× 3.0

Engine	6BTA5.9-C132	Full extended boom length	20m
Rated Power	125kW/2100rpm	Base boom length	8.4m
Max. Torque	660N.m/1600-1800rpm	Max hoisting speed of the hook	16m/min(6 part line)
Fuel Consumption	(<=)224g/kW.h	Grade ability	15%
Max. Lifting Capacity	16000 kg	Fuel Tank	300 L
Max lifting moment /base boom	470.4kn.m	Hydraulic Tank	500
Max lifting moment /full extended boom	282.2kn.m	Working surrounding	-20C-+40C
Max. lifting height /base boom	8.15m	Section distance of chain rail	190mm
Max. lifting height /full extended boom	20m	Track shoe width	Triangle 950/780mm
Overall size	10860x3350x3150mm	Min clearance part from ground	495
Operating Weight	25200kg	Ground Pressure	34kPa
