Marine Double Drums Trawl Winch with 3ton Pulling Capacity
Shandong China Coal Industrial & Mining Supplies Group Co., Ltd.- Type：Hydraulic Winch
- Driven Type：Hydraulic
- Speed：Fast
- Carrying Capacity：Weight Level
- Tonnage：3T
- Reel Number：2
Base Info
- Model NO.：YJ-3
- Running Mode：Stationary
- Certification：CE
- Standard：National Standards
- Factory：Yes
- Experience：20 Years
- Delivery Time：Within 7-10 Days After Receiving Your Payment
- Transport Package：Standard Wooden Case Packing
- Specification：outermost payer pulling capacity: 3ton
- Trademark：china coal
- Origin：Jining City, Shandong Province, China
- HS Code：8425399000
- Production Capacity：400sets,Month
Description
Basic Info.
Model NO. YJ-3 Running Mode Stationary Certification CE Standard National Standards Factory Yes Experience 20 Years Delivery Time Within 7-10 Days After Receiving Your Payment Transport Package Standard Wooden Case Packing Specification outermost payer pulling capacity: 3ton Trademark china coal Origin Jining City, Shandong Province, China HS Code 8425399000 Production Capacity 400sets/MonthProduct Description
Product introduce
Double drum winchThis winch is driven by hydraulic motor.
It consists of main shaft/ opening gears/ drum apparatus/ band brakes/ manual clutches/ frame and auto mechanical spooling devices.
Drum apparatus
It is consisted of main shaft, sliding bearings, drum. gear wheel etc.The drum connect to main shaft by sliding bears.
Working principle of brakes:
Braking: While braking, the brake bank will be tightened by level plate through locking screw.Brake releasing: Loose the locking screw; The brake band will be loose.
If the brake bankd should be replaced, remove all the pins and bolts on the brake band. The brake band will be divided into two parts and can be taken off from the upper side of hub. And at last replace the old bands.
Rope capacity: 10mm x 600m steel wire rope
Rated working load capacity and speed: 3tons x 30m/min ( the first layer )
Braking load capacity: 9tons ( the first layer )
Manual brake, Manual clutch
With spooling device/ hydraulic station
With Changchai 4100 Diesel Engine
Hydraulic pump is running continously while main engine is working.
| Brand | China Coal |
| Packing Details | standard wooden case packing |
| Delivery Time | 5-10 days after your payment |
| Payment Terms | TT, Western Union and Paypal |
| Supply Ability | 1000 sets per month |
| Minimum Order Quantity | 1 set |
| Price Terms | FOB |
| Port | Qingdao,Ningbo,Shanghai,Shenzhen |
