• Model NO.：DY-Winch
• Rated Speed：5-7.5m,Min
• Transport Package：Wooden Case
• Specification：CCS. CE. BV. EC
• Trademark：Deyuan
• Origin：China
• Production Capacity：500set,Month

Basic Info.

Model NO. DY-Winch Rated Speed 5-7.5m/Min Transport Package Wooden Case Specification CCS. CE. BV. EC Trademark Deyuan Origin China Production Capacity 500set/Month

Product Description

Marine Hydraulic single side mooring winch with one drum

Hydraulic Marine Mooring Winch:
Mooring winch is an important winch nearly use on all kinds of boat, it is just like anchor windlass, when ship's berth at port, emergency berting or when tug boat have drag mission mooring winch will be use. From above information you can see the mooring winch is using between ships and platform when ship berthing.

Model	Drum Load (kN)	Speed (m/min)	Capacity (mm×m)	Motor power (kW)
MW1F30	30	15	50×150	18.5
MW1F40	40	15	50×150	18.5
MW1F50	50	15	60×150	22
MW1F60	60	15	70×160	30
MW1F70	70	15	70×160	30
MW1F80	80	15	80×180	37
MW1F100	100	15	80×180	37
MW1F125	125	15	80×200	55
MW1F150	150	15	80×200	75
MW1F200	200	15	100×220	90
MW1F250	250	15	100×220	110

Quality assurance and service
1. Complete and strict management, production and inspection procedures are in place to control quality and avoid errors in details
2. Design and production capability
3. Strict inspection, including incoming material inspection, packaging, etc.
4. Advanced factory equipment is guaranteed
5. Reply to design or effective solutions provided by our engineers or technical support within 24 hours during the working day.
6. Can provide professional customized services according to customer requirements
7. Timely delivery, because we have strict production planning and professional tracking process
8. Affordable price and professional service

If you are interested in our products or have any questions, please feel free to contact us for more details.
Deyuan Marine has been waiting for your contact.
